Specifications
Brand Name :
FLY/AIRWOLF or OEM
Model Number :
RCA15T RCA20T
Certification :
ISO 9001,CE
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
2000 pcs/month
Delivery Time :
5 working days
Packaging Details :
carton
Material :
Diecast Aluminum
Diaphragm and seals :
Nitrile or fluororubber
Spring :
304SS
Outlet Pipe :
Schedule 40 wrought steel zinc passivated
Description

FLY/AIRWOLF T series Remote valve Diaphragm kit K1001 K2000 Pulse jet valve 3/4 inch RCA20T 1/2" RCA15T

Dust collector applications , in particular for reverse pulse jet filter cleaning including bag filters , ceramic filters , and sintered metal fibre filters.

Simple maintenance

Before condcting any maintenance activity on the system ensure that componnents are fully isolated from pressure and power
supplies .Pressure and power should not be reapplied until the valve has been fully assembled.Diaphragm and pilot inspection
should be conducted annually.

Installation

For your safety do not pressurise system until all valves and pipes are fully secured. Do not attempt to remove a
fitted valve while system is under pressure.

1. Prepare supply and blowtube pipes* to suit valve type and specification.
2. Ensure tank and pipes are free from dirt, rust or other particulate.installing valves underneath the tank.
3. Ensure supply air is clean and dry.
4. Mount valves to inlet pipes (or flanges, tighten bolts to 10Nm) and blowtube tovalves, ensuring no excess thread sealant can enter the valve itself. Ensure blowtube is fully inserted into the valve outlet.
5. Tanks and pipes must be independently restrained from FS and DD valves.
6. Connect RCAC pilot port to remote pilot valve, or install MIP/3DS screw in pilot valve.
7. Apply moderate pressure to system and check for installation leaks.
8. Fully pressurise system.
9. Test fire and listen for proper actuation and crisp pulse noise.

Construction
Body Aluminum (Diecast)
Washer SS 304
Armature SS 430FR
Core and Plugnut Stainless steel
Core Spring SS 304
Sealing & disc NBR(nitrile/buna-n)
Screws SS302
Diaphragm PA-6(Standard), fluororubber
Shading coil Copper
Connector DIN43650A
Voltage DC: 24V, AC: 24V, 48V, 110V, 230V
Working Temperature -20 to +85℃ Nitrile seals -29 to +232℃ fluororubber seals
Protection Class IP65
Coil Insulation Class F
Working Pressure 0.35-0.85Mpa
Recommended on time range 50-500ms
Recommended time between pulses 1 minute or Less

Drawings:

CA/RCA20T

FLY/AIRWOLF T Series Remote Valve Diaphragm Kit K1001 K2000 Pulse Jet Valve 3/4 Inch

Photo Show

FLY/AIRWOLF T Series Remote Valve Diaphragm Kit K1001 K2000 Pulse Jet Valve 3/4 Inch
