SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
SMC Rotary actuator CDRA1 Series silver with auto switch CDRA1BS80-180C CDRA1BS63-90C cylinder
Specifications
Brand Name :
SMC
Model Number :
CDRA1BS32-90
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000 pcs /day
Delivery Time :
within 1-10 working days after payment
Packaging Details :
Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement
Name :
Air Cylinder
Model :
CDRA1BS80-180C CDRA1BS63-90C
Material :
aluminium alloy
Ambient and fluid temperature :
0~60℃(No freezing)
Description

SMC Rotary actuator CDRA1 Series silver CDRA1BS80-180C CDRA1BS63-90C cylinder

Caution

No influence on cathode ray tubes by copper ion and fluorine resin. As standard models are already made applicable to copper free styles, they can be applied as they are.

If air pressure is applied from the A side of the direction indication label, the shaft rotates clockwise. If air pressure is applied from the B side, the shaft rotates counterclockwise.

Specifications

Stype Pneumatic Air-hydro
Size 30 50 63 80 100 50 63 80 100
Fluid Air(Non-lube) Hydraulic oil
Max. operating pressure 1MPa
Min. operating 0.1MPa
Ambient and fluid temperature 0~60℃(No freezing)
Cushion None With or without air cushion None
Output(Nm) 1.9 9.3 17 32 74 9.3 17 32 74
Allowable surge prssure - 1.5MPa
Backlash - Within 1
Tolerance in rotating angle - +4
0

Operation Principles

In the diagram below, switch B is ON. When pressure is applied from A, the piston moves to B,causing the shaft to rotate clockwise. At this time,magnet B goes out of the movement range of switch B, causing switch B to turn OFF.Furthermore, the piston moves to the right,causing magnet A to enter the movement range of switch A. As a result, switch A turns ON.

Size

Model Port size
(PT)		 A B C D DD F H J K S U W BA BB CA CB SA SB SC SD SE
CDRA1BS50 1/8 62 48 46 46 25 2.5 36 M8*1.25*8 5 156 98 17 17 8.5 8.5 13 33 13.5 12 14 34
CDRA1BS63 1/8 76 60 57 57 30 2.5 41 M10*1.5*12 5 175 117 19.5 20 10 10 14 33 14.5 12 21 34
CDRA1BS80 1/4 92 72 70 70 35 3 50 M12*1.75*13 5 199 142 22.5 23.5 12 12 18 33 15.5 12 29 34
CDRA1BS100 3/8 112 85 85 85 40 4 60 M12*1.75*14 5 259 172 28 25 12.5 12.5 18 33 16 12 39 34
