Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4 Slivery Cut-off Type Reversing Valve
Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4 Slivery Cut-off Type Reversing Valve
Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4 Slivery Cut-off Type Reversing Valve
Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4 Slivery Cut-off Type Reversing Valve
Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4 Slivery Cut-off Type Reversing Valve
Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4 Slivery Cut-off Type Reversing Valve
Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4 Slivery Cut-off Type Reversing Valve
Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4 Slivery Cut-off Type Reversing Valve
Specifications
Brand Name :
Other
Model Number :
K25JD-08
Certification :
CE
Place of Origin :
China
MOQ :
1 piece
Price :
Negotiation
Payment Terms :
T/T , Western Union
Supply Ability :
1000 pcs
Delivery Time :
within 1-30 working days after payment
Packaging Details :
Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement
Model code :
K25JD-08
Working press :
2-8 bar
Working Temp. :
-5 °C to +50 °C
Port size :
G 1/4
Fluids :
Air
Material :
Aluminum Alloy
Description

Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4" Slivery Cut-off Type Reversing Valve

K25J series 5/2-ways directional valve is a product jointly designed by first ministry of machinery have streamlined structure and reliable actions.

Ordering code

Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4

Features

Model K25JD-6 K25JD-8 K25JD-10 K25JD-15 K25JD-20 K25JD-25
K25JQ-6 K25JQ-8 K25JQ-10 K25JQ-15 K25JQ-20 K25JQ-25
Nominal diameter(mm) 6 8 10 15 20 25
Working pressure range 0.15~0.8MPa
Amount of leakage(cm³/min) ≤10 ≤25 ≤50
Commutation time(s) ≤0.06 ≤0.08 ≤0.12
Commutation frequency(Hz) ≥10 ≥8 ≥5
Ambient temperature -10~55℃
Medium temperature -5~50℃
Circulation capacity S value(mm²) ≥10 ≥20 ≥40 ≥60 ≥120 ≥190
Supply voltage AC: 220V, 110V, 36V DC: 48V, 24V, 12V
Control pressure ≥0.2MPa
Life (1000 times)

≥1500

Dimension

Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4

Model Port size D E F G H L J LD LQ M
K25JD-6 1/8" 8 7 75 14 85 102 14 136 90 G1/8
K25JQ-6
K25JD-8 1/4" 6 90
K25JQ-8
K25JD-10 3/8" 12 10 108 19 116 138 19 151 100
K25JQ-10
K25JD-15 1/2" 10 120
K25JQ-15
K25JD-20 3/4" 12 13 160 30 180 208 30 220 150
K25JQ-20
K25JD-25 1"
K25JQ-25

Pictures and details

Single Electronic Control 5/2 Way Aluminium Alloy K25JD-08 1/4

Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNL will be normal ways. If you require use of a courier, we can do it.

Competitive Advantage

Our product features Our Services Guarantee:
1) Competitive price 1) Prompt respond (Reply with 24 hours)
2) Good quality 2) Free Samples (Customer pay for the delivery cost)
3) Professional Packaging 3) Registration support.
4) Produce according to Customers’ instruction 4) Photos/videos are available during production.
5) None delay shipment 5) Loading inspection, and send loading photos before shipment.

After-sale Service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.


Warranty
All item Comes with Basic 3 Month Sellers Warranty, if item defective in 3 Month, We will offer replacement without extra Charger(including shipping fee)After we Receive the Defective item.
If item Defective after 3 Month, Buyers can still send it back, We will contact suppliers or Manufactory for Warranty. Buyers Might Need to pay the Shipping fee For resend the replaced item.
