FESTO Whisker valve FVS-3-1/8 3876 Pneumatic Manual Valve
FESTO Whisker valve FVS-3-1/8 3876 Pneumatic Manual Valve
FESTO Whisker valve FVS-3-1/8 3876 Pneumatic Manual Valve
FESTO Whisker valve FVS-3-1/8 3876 Pneumatic Manual Valve
FESTO Whisker valve FVS-3-1/8 3876 Pneumatic Manual Valve
FESTO Whisker valve FVS-3-1/8 3876 Pneumatic Manual Valve
FESTO Whisker valve FVS-3-1/8 3876 Pneumatic Manual Valve
FESTO Whisker valve FVS-3-1/8 3876 Pneumatic Manual Valve
Specifications
Brand Name :
FESTO
Model Number :
FVS-3-1/8
Place of Origin :
China
MOQ :
1pc
Price :
EXW USD100-120
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
500 pcs per month
Delivery Time :
4-5 weeks
Packaging Details :
Plastic bag, Carton
Type :
FVS-3-1/8
Brand :
FESTO
Part no :
3876
Valve function :
3/2-way, closed, monostable
Type of actuation :
Mechanical
Media temperature :
-10°C-60°C
Description

FESTO Whisker valve FVS-3-1/8 3876 Pneumatic Manual Valve

About product

Small and compact for a wide range of pneumatic applications

Flexibility of the pneumatic working ports provides a practical solution to different requirements

Durable with proven piston slide and piston poppet valves

Sturdy thanks to metal or plastic housing and connecting thread or connector

Front panel mounting or mounting on bracket

Technical Data

Valve function 3/2-way, closed, monostable
Type of actuation Mechanical
Standard nominal flow rate 146 l/min
pneumatic working port G1/8
Design Poppet seat
Type of reset Mechanical spring
Nominal size 3.5 mm
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position optional
Type of piloting Pilot actuated
Pilot air supply Internal
Flow direction Non-reversible
Symbol 00991119
Pilot medium Compressed air to ISO 8573-1:2010 [-:-:-]
Note on forced dynamization Switching frequency min. 1/year
Operating medium Compressed air to ISO 8573-1:2010 [-:-:-]
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -10°C-60°C
Ambient temperature -10°C-60°C
Product weight 130 g
Type of mounting With through-hole
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Pneumatic connection, port 3 G1/8
Note on materials RoHS-compliant
Material seals NBR
Material housing Aluminium Anodised

There are many models . Please contact me!
