About product
1.Available with ball screw drive (size 32 … 100) or lead screw (size 32 … 50).
2.Ball screw: with three spindle pitches for selecting the optimal force-speed ratio.
3.Optional: high corrosion protection, degree of protection IP65, food-safe (see www.festo.com/certificates/ESBF), piston rod extension.
Advantage
1.High corrosion protection.
2.Degree of protection IP65.
3.Extended piston rod.
4.NSF-H1 lubricant for food & beverage industry applications.
5.Extensive accessories.
Technical Data
Size | 80 |
Stroke | 100 mm |
Piston rod thread | M20x1.5 |
Spindle diameter | 32 mm |
Spindle pitch | 32 mm/U |
Based on standard | ISO 15552 |
Mounting position | optional |
Piston-rod end | Male thread |
Type of motor | Servo motor |
Position detection | Via proximity switch |
Design | Electric cylinder with ball screw |
Spindle type | Ball screw |
Symbol | 00991941 |
Protection against torque/guide | With plain-bearing guide |
Corrosion resistance class CRC | 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364 zone III |
Storage temperature | -20°C-60°C |
Degree of protection | IP40 |
Ambient temperature | 0°C-60°C |
Basic weight for 0 mm stroke | 7393 g |
Additional weight per 10 mm stroke | 155 g |
Type of mounting | Via female thread Or accessories |
Interface code, actuator | D80 |
Note on materials | RoHS-compliant |
Material cover | Cast aluminium, coated |
Material piston rod | High-alloy stainless steel |
Material screws | Galvanised steel |
Material spindle nut | Rolled steel |
Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
General technical data
