VUVG-L14-M52-AT-G18-1P3 Festo Solenoid Valve 566499 GTIN4052568100209
VUVG-L14-M52-AT-G18-1P3 Festo Solenoid Valve 566499 GTIN4052568100209
VUVG-L14-M52-AT-G18-1P3 Festo Solenoid Valve 566499 GTIN4052568100209
VUVG-L14-M52-AT-G18-1P3 Festo Solenoid Valve 566499 GTIN4052568100209
Specifications
Brand Name :
FESTO
Model Number :
VUVG-L14-M52-AT-G18-1P3
Place of Origin :
China
MOQ :
1pc
Price :
EXW USD50-60
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
100 pcs per month
Delivery Time :
7-10 working days
Packaging Details :
Plastic bag, Carton
Model :
VUVG-L14-M52-AT-G18-1P3
Order no :
566499
Brand :
FESTO
Product weight :
78 g
Material housing :
Wrought aluminium alloy
Valve function :
5/2-way, monostable
Description

FESTO Solenoid valve VUVG-L14-M52-AT-G18-1P3 566499 GTIN4052568100209 Pneumatic Solenoid Valves

About product

1.Pneumatic spring return.

2.Internal pilot air supply.

3.Sturdy and durable metal components.

4.Choice of quick push-in connectors.

5.Piston spool with sealing cartridge (VUVG-L, VUVG-B).

Technical Data

Valve function 5/2-way, monostable
Type of actuation Electric
Valve size 14 mm
Standard nominal flow rate 700 l/min ... 780 l/min
pneumatic working port G1/8
Operating voltage 24V DC
Design Piston gate valve
Type of reset Pneumatic spring
Approval RCM trademark c UL us - Recognized (OL)
Degree of protection IP40 IP65 With plug socket
Nominal size 5.6 mm
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position optional
Manual override Detenting Non-detenting Covered
Type of piloting Pilot actuated
Pilot air supply Internal
Symbol 00992908
lap Positive overlap
Suitability for vacuum no
Switching time off 22 ms
Switching time on 14 ms
Duty cycle 100%
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -5°C-60°C
Ambient temperature -5°C-60°C
Product weight 78 g
Electrical connection Via electrical sub-base
Type of mounting Either: On manifold rail With through-hole
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Pneumatic connection, port 3 G1/8
Pneumatic connection, port 4 G1/8
Pneumatic connection, port 5 G1/8
Note on materials RoHS-compliant
Material seals HNBR NBR
Material housing Wrought aluminium alloy


Another size as below

Type Order no Price
VUVG-L14-T32-AT-G18-P3 566496 USD50-60
VUVG-L14-32U-AT-G18-1P3 566497 USD50-60
VUVG-L14-T32H-AT-G18-1P3 566498 USD50-60
VUVG-L14-T32C-MT-G18-1P3 574368 USD50-60
VUVG-L14-T32U-MT-G18-1P3 574369 USD50-60
VUVG-L14-T32H-MT-G18-1P3 574370 USD50-60
VUVG-L14-T32C-AZT-G18-1P3 566505 USD50-60
VUVG-L14-T32U-AZT-G18-1P3 566506 USD50-60
VUVG-L14-T32H-AZTG18-1P3 566507 USD50-60
VUVG-L14-T32C-MZT-G18-1P3 574372 USD50-60
VUVG-L14-T32U-MZT-G18-1P3 574373 USD50-60
VUVG-L14-T32H-MZT-G18-1P3 574374 USD50-60
VUVG-L14-M52-AT-G18-1P3 566499 USD50-60
VUVG-L14-M52-MT-G18-1P3 574371 USD50-60
VUVG-L14-M52-AZT-G18-1P3 566508 USD50-60
VUVG-L14-M52-MZT-G18-1P3 574375 USD50-60
VUVG-L14-B52-T-G18-1P3 566500 USD50-60
VUVG-L14-B52-ZT-G18-1P3 566509 USD50-60

Datasheet

VUVG-L14-M52-AT-G18-1P3 Festo Solenoid Valve 566499 GTIN4052568100209

There are so many products, welcome to enquire!
