Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
Pneumatic FESTO Compact Cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051
Specifications
Brand Name :
FESTO
Model Number :
ADNGF-20-60-P-A
Place of Origin :
China
MOQ :
1pc
Price :
EXW USD40-50
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
50 pcs per month
Delivery Time :
10-15working days
Packaging Details :
plastic bag, carton，OPP bag
Brand :
FESTO
Type :
ADNGF-20-60-P-A
Part no :
554228
GTIN :
4052568006051
Piston diameter :
20 mm
Stroke :
60 mm
Description

FESTO Compact cylinder ADNGF-20-60-P-A 554228 GTIN4052568006051 Pneumatic Air Cylinders

About product

Cushioning types Cushioning P
Mode of operation The drive has elastic polymer flexible end-position cushioning
Application Small loads
Low speeds
Small cushioning capacity
Advantages No adjustment required
Time-saving

Technical Data

Stroke 60 mm
Piston diameter 20 mm
Based on standard ISO 21287
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Design Piston Piston rod Profile barrel
Position detection Via proximity switch
Protection against torque/guide Guide rod with yoke
Mode of operation Double-acting
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20°C-80°C
Basic weight for 0 mm stroke 161 g
Additional weight per 10 mm stroke 26 g
Pneumatic connection M5
Note on materials RoHS-compliant
Material cover Aluminium Anodised
Material seals TPE-U(PUR)
Material piston rod High-alloy steel
Material cylinder barrel Wrought aluminium alloy Smooth anodised

Other size as below

Type Order no Weight(g) Price
ADNGF-20-5-P-A 554220 174 USD40-50
ADNGF-20-10-P-A 554221 187 USD40-50
ADNGF-20-15-P-A 554222 200 USD40-50
ADNGF-20-20-P-A 554223 213 USD40-50
ADNGF-20-25-P-A 554224 226 USD40-50
ADNGF-20-30-P-A 554225 239 USD40-50
ADNGF-20-40-P-A 554226 265 USD40-50
ADNGF-20-50-P-A 554227 291 USD40-50
ADNGF-20-60-P-A 554228 317 USD40-50

FESTO, the world's leading automation technology supplier, is committed to promoting the development of industrial automation with intelligent and convenient solutions. FESTO works with you to improve productivity.
