NF353A044 Explosion Proof Coil Pulse Solenoid Valve 1 Inch Threaded Diaphragm Valve
NF353A044 Explosion Proof Coil Pulse Solenoid Valve 1 Inch Threaded Diaphragm Valve
NF353A044 Explosion Proof Coil Pulse Solenoid Valve 1 Inch Threaded Diaphragm Valve
NF353A044 Explosion Proof Coil Pulse Solenoid Valve 1 Inch Threaded Diaphragm Valve
NF353A044 Explosion Proof Coil Pulse Solenoid Valve 1 Inch Threaded Diaphragm Valve
NF353A044 Explosion Proof Coil Pulse Solenoid Valve 1 Inch Threaded Diaphragm Valve
NF353A044 Explosion Proof Coil Pulse Solenoid Valve 1 Inch Threaded Diaphragm Valve
NF353A044 Explosion Proof Coil Pulse Solenoid Valve 1 Inch Threaded Diaphragm Valve
Specifications
Brand Name :
FLY,AIRWOLF
Model Number :
NF353A044
Certification :
CE
Place of Origin :
CHINA
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
Western Union, T/T, L/C, Paypal, Credit card
Supply Ability :
2000 pieces per 10 working days
Delivery Time :
1-7 work days
Packaging Details :
Plastic bags, boxes, cartons, Pallets or As customer's requirement
Model :
NF353A044
Temperature :
-20 to +85°C
Pressure :
0,35 - 8,5 bar [1 bar = 100kPa]
Fluid :
Air
Description

NF353A044 Explosion proof coil Pulse Solenoid valve 1inch Threaded Diaphragm valve

FEATURES

• The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation
• The high flow, angle type bodies, springless construction, in combination with the special diaphragm assemblies give the unique operating features required for dust collector service applications
• The design with integral compression fittings will facilitate installation because there is no need for threaded piping
• Built-in silencers guarantee noise free operation and avoid foreign particles entering the valve
• The integral operators are provided with epoxy moulded F-class coils. Various optional waterproof and explosionproof solenoids for use in potentially explo- sive atmospheres (gas & dust) according to Directive ATEX 94/9/EC can be mounted on the same basic valve (see page 45 till 52)
CONSTRUCTION
Body Aluminium
Core tube Stainless steel
Core and plugnut Stainless steel
Core spring Stainless steel
Sealings & disc NBR (nitrile / buna-n)
Diaphragm TPE (hytrel)
Shading coil Copper
Coil insulation class F
Connector Spade plug (cable Ø 6 - 10 mm)
Connector specification ISO 4400
Electrical safety IEC 335
