Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump
Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump
Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump
Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump
Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump
Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump
Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump
Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump
Specifications
Brand Name :
Janus
Model Number :
VP-08-FA3 VP-12-FA3 VP-15-FA3 VP-20-FA3 VP-30-FA3 VP-40-FA3
Place of Origin :
China Taiwan
MOQ :
1
Price :
35-55USD
Payment Terms :
T/T, Western Union, MoneyGram,Paypal
Supply Ability :
500 pcs per week
Delivery Time :
3-12working days
Packaging Details :
poly bags, box, cartons, pallets
Standard Pressure :
103.5 Bar (1500 PSI) AC 207 Bar (3000 PSI) DC
Body Material :
Carbon Steel
Shift Type :
Soft
Mounting type :
Foot and Flange
Noise :
Low
Pump output flow :
Cam ring
Description

Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump

Codes:

VP-08-FA3
VP-12-FA3
VP-15-FA3
VP-20-FA3
VP-30-FA3
VP-40-FA3

VP Series pump possesses vane construction with pressure compensated units.The design is
to provide only the flow required by the system.Pump output flow is controlled by cam ring
Cam ring is controlled by the compensating mechanism of the pump.They are designed for
low noise,high efficiency and longer life-span.

Weight:
Foot type VP-12/15/20: 6kgs VP-30/40 12.5kgs
Flange type :VP-12/15/20: 5kgs VP-30/40 9.5kgs

Dimensions:

Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump

Taiwan Den Sen Janus VP-08-FA3 Variable Vane Pump
