Festo Type Pneumatic Poppet Valve , XMFH Series Tiger Solenoid Pneumatic Valve
Festo Type Pneumatic Poppet Valve , XMFH Series Tiger Solenoid Pneumatic Valve
Specifications
Brand Name :
PRIUS,XINYI or OEM
Model Number :
XMFH-5-02
Place of Origin :
Ningbo,China
MOQ :
50pcs
Price :
negotiation
Payment Terms :
T/T, L/C, Western Union,Paypal
Supply Ability :
5000pcs per month
Delivery Time :
10~15 working days
Packaging Details :
bag+box+catons+pallet
name :
Tigger Valve
Working Medium :
air/oxygen/rare gases
Max Pressure :
0.4Mpa
Pressure Range :
0~0.35Mpa
Temperature Range :
-5~60℃
Port Size :
G1/4"
Net Weight :
0.4kg/pcs
Voltage :
DC12V,DC24V
Class of Insulation :
F class
Cv :
0.89
Description

Festo Type Pneumatic Poppet Valve , XMFH Series Tiger Solenoid Pneumatic Valve

Specifiction

Port Size G1/8 G1/4
Valve function 5/2-way, single solenoid
Constructional design Poppet valve
Sealing principle Soft
Actuation type Electrical
Type of reset Mechanical spring
Type of control Piloted
Direction of flow Non reversible
Pilot air supply Internal or external
Exhaust function With flow control
Manual override Detenting
Type of mounting Via through holes
Mounting position Any
Standard nominal flow rate (l/min) 500
Product weight (g) 360
Working Medium Filtering compressed air, lubrication or lubrication
Operating Pressure (bar) 2~8
Pilot pressure (bar) 1~8
Ambient temperature (℃) -5~40
Temperature of medium (℃) -10~60

Festo Type Pneumatic Poppet Valve , XMFH Series Tiger Solenoid Pneumatic ValveFesto Type Pneumatic Poppet Valve , XMFH Series Tiger Solenoid Pneumatic Valve
