SS304 Tube Pneumatic 1 / 4 Inch Solenoid Valve , Two Way Solenoid Valve
SS304 Tube Pneumatic 1 / 4 Inch Solenoid Valve , Two Way Solenoid Valve
SS304 Tube Pneumatic 1 / 4 Inch Solenoid Valve , Two Way Solenoid Valve
SS304 Tube Pneumatic 1 / 4 Inch Solenoid Valve , Two Way Solenoid Valve
Specifications
Brand Name :
BRANDO
Model Number :
BR2
Certification :
CE ISO
Place of Origin :
Ningbo, China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
1000000PCS PER MONTH
Delivery Time :
Negotiation
Packaging Details :
Inner box, carton, then packed by pallet
Part Name :
RO solenoid valve for water purifier system
Body material :
POM, PP, also can be customized
Voltage :
12v DC, 24v DC, 36v DC
Working Pressure :
0--120PSI
Orifice :
2.5mm
Connecting Port Type :
1/4" normal thread
Description

SS304 Tube Pneumatic 1 / 4 Inch Solenoid Valve , Two Way Solenoid Valve

Quick details of our RO system application solenoid valve

1, Application: Reverse osmosis water purifier system solenoid valve

2, Number of pass: 2 way 2 way

3, Pipe port size: 1/4"

4, Working medium: water

5, Working pressure: 0 to 125 psi

6, Orifice: 2.5mm

7, Valve voltage: DC12V, 24V, 36V, 48V, AC24V, 110V, 220V

8, Material: enamelled copper wire, POM body, SS304 tube

9, Seal: NBR, Viton, EPDM, Silicone, all can be customized

Detailed specifications of ro solenoid valve for reverse osmosis water purifier:

Part name Solenoid Valve for Reverse Osmosis water purifier system application
Application Reverse Osmosis RO water purifer system
Principium Directly acting type
Pattern Two-port two-position
Control mode Normally close
Medium Water
Medium temperature 0~100°C
Working pressure 0~125psi
Max pressure 10bar
Connecting port size 1/4"
Connecting port type Normally thread type, or fast fitting type
Orifice 2.5mm
Valve voltage DC12V 24V 36V 48V, AC24V 110V 220V
Coil material enamelled copper wire
Armature plunger assembly SS304, 430FR
Body material PP, POM all available
Seal NBR:-10℃ to 80℃ EPDM:-10℃ to 120℃ VITON:-30℃ to 150℃
Spring material SS304
Packaging Inner box, carton, then packed by pallet
Delivery time According to your order quantity, normally 2 weeks

High quality plunger tube assembly also on sale:

SS304 Tube Pneumatic 1 / 4 Inch Solenoid Valve , Two Way Solenoid Valve

Our advantages:

1, We have more than 10 years experience in solenoid valves.
2, Excellent quality control is one of our main principles.

3, Our design, producing and testing are strictly complied with ISO9001 standard.
4, Now our products are being exported all over the world.
5, We provide OEM service, accept customer label, develop the product with your drawings or samples.
6, Any question, will be replyed within 12 hours.
7, Direct supplying from the factory, shorten the distance between the manufacturer and the customer.

Welcome your any question, we will response at once. We also can produce as customized.

Welcome your drawing or sample.
