24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve
24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve
Specifications
Brand Name :
BRANDO
Model Number :
BB14040007
Certification :
None
Place of Origin :
Ningbo, China
MOQ :
200
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
200000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Inner Box, Carton, Pallet
Product Name :
Pulse Valve Solenoid Coil
Ordering Code :
400425-142, 400425-117
Voltage :
24VDC, 220VAC
Power :
9.5W, 10.5W, 11.2W
Insulation Class :
H, F
Temperature Class :
T, B, F
Connector :
DIN43650A
Fitted Pulse Valve Model :
SCG353A047, SCG353A050, SCG353A051
Description

24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve

This is a solenoid coil for asco pulse valve SCG353A047, SCG353A050, SCG353A051; ordering code: 400425-142, 400425-117; voltage: 24VDC, 220VAC; power: 9.5W, 10.5W, 11.2W; insulation class: H, F; temperature class: T, B, F; connector type: DIN 43650 Form A.

Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.

Ordering Code of Solenoid Valve Coil:

Voltages
24V DC
48V DC
24V AC
48V AC
115V AC
230V AC
FT
400325-142
400325-144
400325-101
400325-105
400325-118
400325-117
FB
400325-242
400325-244
400325-201
400325-205
400325-218
400325-217
FT
400425-142
400425-144
400425-101
400425-105
400425-118
400425-117
FB
-
-
400425-201
400425-205
400425-218
400425-217
FF
400425-342
400425-344
-
-
-
-

Dimension & Data of Solenoid Coil, Armature for ASCO Pulse Valve:

24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve

BRANDO Model
BB14040007
Voltage

12VDC, 24VDC,

24VAC, 110VAC, 220VAC
Power
21VA, 28VA,
10W, 11W, 18W, 30W
Insulation Class
H, F
Temperature Class
T, B, F
Connector
DIN 43650 Form A
Fitted Pulse Valve Model
SCG353A047
SCG353A050
SCG353A051

24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve

BRANDO Model
BAPC214041405
Plunger Tube Material
Stainless Steel
Seal Material
NBR
Fitted Pulse Valve Model
SCG353A047
SCG353A050
SCG353A051


Video of 400425-142, 400425-117 Solenoid Coil:

BRANDO Solenoid Valve Coils Production Video:

More ASCO Type Pulse Valves for you to choose:

24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve 24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve 24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve 24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve
Threaded Type Remote Pilot Type Straight Through Type Submerged Type
24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve 24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve 24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve 24VDC 11.2W 400425-142 Solenoid Coil For ASCO Dust Collector Pulse Valve
Diaphragm Solenoid Coil Solenoid Armature Pulse Controller
