EVR 15 NC Danfoss Type Solenoid Valve 5/8'' SAE 032F8101 032L8101 24V 110V 220V
EVR 15 NC Danfoss Type Solenoid Valve 5/8'' SAE 032F8101 032L8101 24V 110V 220V
Specifications
Brand Name :
BRANDO
Model Number :
EVR 15
Certification :
CE, ISO
Place of Origin :
Ningbo, China
MOQ :
100pcs
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
50000pcs per month
Delivery Time :
15 working days
Packaging Details :
Box, Carton, Pallet
Product Name :
Refrigeration Solenoid Valve
Code No :
032F8101, 032L8101
Working Medium :
Refrigerant
Applicable Refrigerants :
CFC, HCFC, HFC
Port Size :
5/8''
Connection Type :
Flare (SAE)
Function :
2 Way Normally Closed
Operation :
Servo-diaphragm
Coil Option :
BE (Standard), BF, BG (Optional)
Coil Voltage :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Application :
HVAC, Air Conditioning, Water Chiller, Freezer, etc
Description

EVR 15 NC Danfoss Type Solenoid Valve 5/8'' SAE 032F8101 032L8101 24V 110V 220V

This is EVR 15 solenoid valve, 032F8101 or 032L8101 code number, 5/8'' flare (SAE) port, 2 way normally closed, diaphragm pilot operated, can be installed with BE, BF or BG coil, various voltages for selection, 12VDC, 24VDC, 24VAC, 110VAC or 220VAC, other voltages can be customized, popularly used in refrigeration, freezing and air conditioning plant applications in liquid, suction, and hot gas lines with refrigerants.

More Options for you:
1. Connection Type: Flare (SAE), Solder (ODF)
2. Port Size: 1/4'', 3/8'', 1/2'', 5/8'', 3/4'' , 7/8'', 1-1/8'', 1-3/8'', 1-5/8'', 2-1/8''
2. Coil Type: BE, BF, BG
3. Coil Voltage: 12VDC, 24VDC, 24VAC, 48VAC, 115VAC, 220V-230VAC, 240VAC, 380V-400VAC

EVR 15 NC Danfoss Type Solenoid Valve 5/8'' SAE 032F8101 032L8101 24V 110V 220V

Main Dimension:

EVR 15 NC Danfoss Type Solenoid Valve 5/8'' SAE 032F8101 032L8101 24V 110V 220V

Model
Port (SAE)
H1
H2
H3
L
inch
mm
EVR 2
1/4''
6
14
73
9
75
EVR 3
1/4''
6
14
73
9
75
3/8''
10
14
73
9
75
EVR 6
3/8''
10
14
78
10
82
1/2''
12
14
78
10
88
EVR 10
1/2''
12
16
79
11
103
5/8''
16
16
79
11
110
EVR 15
5/8''
16
19
86
-
131

EVR 15 NC Danfoss Type Solenoid Valve 5/8'' SAE 032F8101 032L8101 24V 110V 220V

Model
Port (ODF)
H1
H2
H3
L
inch
mm
EVR 2
1/4''
6
14
73
9
102
EVR 3
1/4''
6
14
73
9
102
3/8''
10
14
73
9
117
EVR 6
3/8''
10
14
78
10
111
1/2''
12
14
78
10
127
EVR 10
1/2''
12
16
79
11
127
5/8''
16
16
79
11
160
EVR 15
5/8''
16
19
86
-
176
7/8''
22
19
86
-
176
EVR 20
7/8''
22
20
90
-
191
1-1/8''
28
20
90
-
214
EVR 22
1-3/8''
35
20
90
-
291
EVR 25
1-1/8''
28
38
138
-
256
1-3/8''
35
38
138
-
281
EVR 32
1-3/8''
35
47
111
-
281
1-5/8''
42
47
111
-
281
EVR 40
1-5/8''
42
47
111
-
281
2-1/8''
54
47
111
-
281
