K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables
K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables
K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables
K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables
K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables
K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables
Specifications
Brand Name :
BRANDO
Model Number :
K36
Certification :
CE, ISO
Place of Origin :
Ningbo, China
MOQ :
50pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
200000 pcs per month
Delivery Time :
7 to 14 working days
Packaging Details :
Box, Carton, Pallet
Product Name :
Pneumatic Ball Vibrator
Port Size :
G3/8''
Vibration (6 bar) :
10000 RPM
Centrifugal Force (6 bar) :
4050 N
Description

K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables​

This is K36 pneumatic ball vibrator. Pneumatic vibrator is a versatile piece of equipment that is essential to many industries. For example, the pneumatic vibrator is used to remove excess moisture and pockets of air from freshly poured concrete ensuring that the end result is uniform, attractive and above all, safe. In agricultural settings these easy to use vibrators are responsible for emptying silos, among other things, while in pharmaceuticals a pneumatic vibrator can separate fine powders or be used as a feeding mechanism.

Main Dimension of K Series Pneumatic Ball Vibrators:

K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables

Model
A
(mm)
Width
(mm)
C
(mm)
D
(mm)
E
(mm)
F
(mm)
G
(mm)
H
(Thread)
K-8
50
20
86
68
12
7
40
G1/4''
K-10
50
20
86
68
12
7
40
G1/4''
K-13
65
24
113
90
16
9
50
G1/4''
K-16
65
27
113
90
16
9
50
G1/4''
K-20
80
33
128
104
16
9
60
G1/4''
K-25
80
38
128
104
16
9
60
G1/4''
K-30
100
44
160
130
20
11
80
G3/8''
K-36
100
50
160
130
20
11
80
G3/8''


Technical Data of K Series Pneumatic Ball Vibrators:

Model
Vibrations
(x1000 RPM)
Centrifugal Force
(N)
Air Consumption
(l/min)
2 bar
4 bar
6 bar
2 bar
4 bar
6 bar
2 bar
4 bar
6 bar
K-8
25.5
31.0
35.0
130
260
360
83
145
195
K-10
22.5
28.0
34.5
250
470
710
92
150
200
K-13
15.0
18.5
22.5
320
550
870
94
158
225
K-16
13.0
17.0
19.5
450
800
1100
122
200
280
K-20
10.5
14.5
16.5
720
1220
1720
130
230
340
K-25
9.2
12.2
14.0
930
1570
2050
160
290
425
K-30
7.8
9.7
12.5
1510
2470
3210
215
375
570
K-36
7.3
9.0
10.0
2060
3150
4050
260
475
675


Construction of K Series Pneumatic Ball Vibrators:

K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables

More Pneumatic Vibrators for your to choose:

K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables

GT Series

Pneumatic Turbine Vibrators

K Series

Pneumatic Ball Vibrators

R Series

Pneumatic Roller Vibrator

More Accessories for Pneumatic Vibratos:

K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables K36 Findeva Type Pneumatic Ball Vibrator For Vibrating Tables
Pneumatic Fitting Pneumatic Silencer

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
