3 CA76T Goyen Type Pulse Jet Diaphragm Valve For Dust Collector 24V DC 220V AC
3 CA76T Goyen Type Pulse Jet Diaphragm Valve For Dust Collector 24V DC 220V AC
Specifications
Brand Name :
Brando
Model Number :
CA76T
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Inner Box, Carton, Pallet
Product Name :
CA76T Pulse Jet Valve
Remote or Integral Pilot :
Integral Pilot
Port Size :
3''
Structure :
Diaphragm
Diaphragm Material :
NBR (Buna)
Threaded Pulse Jet Valve :
CA15T, CA20T, CA25T, CA35T, CA45T, CA50T, CA62T, CA76T
Dresser Nut Pulse Jet Valve :
CA25DD, RCA25DD, CA45DD
Immersion Pulse Jet Valve :
CA50MM, CA62MM, CA76MM, CA89MM
Flanged Pulse Jet Valve :
CAC25FS, CAC45FS
Remote Pilot Pulse Jet Valve :
RCA3D2, RCA25DD, RCA45T, RCA50T
Working Pressure Range :
0.35 to 0.85 MPa
Voltage :
24VDC, 220VAC
Description

3'' CA76T Goyen Type Pulse Jet Diaphragm Valve For Dust Collector 24V DC 220V AC

CA & RCA Series Pulse Jet Valves:

1. Threaded Pulse Jet Valve: CA15T, CA20T, CA25T, CA35T, CA45T, CA50T, CA62T, CA76T

2. Dresser Nut Pulse Jet Valve: CA25DD, RCA25DD, CA45DD

3. Immersion Pulse Jet Valve: CA50MM, CA62MM, CA76MM, CA89MM

4. Flanged Pulse Jet Valve: CAC25FS, CAC45FS

5. Remote Pilot Pulse Jet Valve: RCA3D2, RCA25DD, RCA45T, RCA50T

Technical data of T Series Pulse Jet Valve:

Model No
CA15T
CA20T
CA25T
CA35T
CA40T
CA50T
CA62T
CA76T
Nonimal size
φ15
φ20
φ25
φ35
φ40
φ50
φ62
φ76
Port Size
G1/2''
G3/4''
G1''
G1 1/4''
G1 1/2''
G2''
G2 1/2''
G3''
Working pressure
0.3 to 0.8MPa
Temp. range
-5℃ to 55℃
Relative humidity
≤85%
Working
medium
Compressed air
Service life
Over 1000000 times
Voltage
DC24V, AC24V, AC110V, AC220V

Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.

List of All CA Series Pulse Jet Valves:

Thread Valve
1/2''
3/4''
1''
1.5''
1.5''
2''
2.5''
3''
CA15T
CA20T
CA25T
CA35T
(Single Diaphragm)
CA45T
(Double Diaphragm)
CA50T
CA62T
CA76T
Dresser Nut Valve
1''
1.5''
CA25DD
CA45DD
Flange Valve
1.5'' Inlet
2'' Inlet
CAC25FS
CAC45FS
Immersion Valve
φ60 Outlet
φ75 Outlet
φ89 Outlet
φ86 Outlet
CA50MM
CA62MM
CA76MM
CA89MM
Remote Pilot Valve
1/8''
1''
1.5''
2''
RCA3D2
RCA25DD
RCA45T
RCA50T

Main Dimension of CA76T Pulse Jet Valve:

3

Product Features:
1. Ready for use in any dust collector design
*For noxious substance control and environmental dust management

2. Cost savings
*Increased pulse efficiency, reduced energy consumption
*Durable materials and wide temperature range enhance lifespan
*Longer filter life, lower dust collector OPEX

3. Compliance
*With environmental and health & safety regulations

4. Ease of installation
*No welding required with 90° connections directly onto squaretanks

Brando Supply:

3333

BFEC Pulse Jet Valve CA/RCA Pulse Jet Valve 353 Pulse Jet Valve Other Pulse Jet Valve

3333

Pulse Controller Diaphragm Repair Kit Solenoid Valve Coil Solenoid Valve Armature Assembly

Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any problem and inquiry!
