1/2'' High Pressure Water Air Solenoid Valve 16 MPa 110V 220V 12 MPa 12V 24V
1/2'' High Pressure Water Air Solenoid Valve 16 MPa 110V 220V 12 MPa 12V 24V
1/2'' High Pressure Water Air Solenoid Valve 16 MPa 110V 220V 12 MPa 12V 24V
1/2'' High Pressure Water Air Solenoid Valve 16 MPa 110V 220V 12 MPa 12V 24V
Specifications
Brand Name :
BRANDO
Model Number :
H1S15B04
Certification :
CE, ISO
Place of Origin :
Ningbo, China
MOQ :
1pc
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
4 to 7 working days
Packaging Details :
Box, Carton, Pallet
Product Name :
High Pressure Solenoid Valve
Port Size :
1/2''
Orifice Size :
15mm
Operation :
Piston Pilot Operated
Function :
2/2 Way Normally Closed
Body Material :
Stainless Steel 304
Seal Material :
PTFE
Working Medium :
Water, Air, Gas, Liquid, etc
Max Working Pressure :
160 bar
Voltage :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Description

1/2'' High Pressure Water Air Solenoid Valve 16 MPa 110V 220V 12 MPa 12V 24V

Product Features:

1. Working Medium: Air, Water, Gas, Liquid, etc
2. Max Working Pressure: 160 bar (See the parameter table below for details)
3. Seal Material: PTFE
4. Body Material: Stainless Steel 304
5. Port Size: 3/8'', 1/2'', 3/4'', 1''
6. Orifice Size: 10mm, 15mm, 20mm, 25mm
7. Operation: Piston Pilot Operated
8. Function: 2 Way Normally Closed
9. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data:

Model No
Orifice
Size
(mm)
Port
Size
(Inch)
CV
Working Pressure
(bar)
Body Material
Seal Material
Function
220VAC
24VDC
H1S10B03
10
3/8''
3.5
6 to 160
6 to 120
SS304
PTFE
2 Way NC
H1S15B04
15
1/2''
4.7
6 to 160
6 to 120
H1S20B06
20
3/4''
7.0
6 to 160
6 to 120
H1S25B25
25
1''
11.0
6 to 160
6 to 120

Main Dimension:

1/2'' High Pressure Water Air Solenoid Valve 16 MPa 110V 220V 12 MPa 12V 24V

Model No
Port Size
A
B
C
H1S10B03
3/8''
60
55
109
H1S15B04
1/2''
70
65
119
H1S20B06
3/4''
80
74
124
H1S25B25
1''
90
87
134

Our Production:

1/2'' High Pressure Water Air Solenoid Valve 16 MPa 110V 220V 12 MPa 12V 24V

FAQ:

Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.

Question 2: How can you tell if your solenoid is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.

Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, orifice size, temperature, pressure, voltage, response time and certification required for your application.
