Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT
Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT
Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT
Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT
Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT
Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT
Specifications
Brand Name :
Brando
Model Number :
4V210-08
Certification :
CE
Place of Origin :
China
MOQ :
200pcs
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
200000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Individual box, Carton, Pallet
Product Name :
AirTAC Type Pneumatic Solenoid Valve
Port Size :
Inlet=Outlet=1/4'', Exhaust=1/8''
Thread Type :
G, NPT, PT, BSP
Valve Type :
Single Solenoid, 5 Way 2 Position
Voltages :
12VDC, 24VDC, 110VAC, 220VAC
Application :
Pneumatic Cylinder, Pneumatic Actuator
Description

Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT

This is 4V210-08 AirTAC type pneumatic solenoid valve, 1/4'' inlet & outlet port size, 1/8'' exhaust port size, (G, NPT, PT, BSP) thread types for you to selection, single solenoid, 5 way 2 position. The electric directional control valve controls the air flow by energizing the solenoid valve. These components are designed to stop, start or change the direction of the airflow. Brando offers multiple port and position configurations. Most air control valves are available with 220VAC, 110VAC, 24VDC or 12VDC solenoid coils. Select from 5/2 way, 5/2 way or 3/2 way.

Data of 4V Series Pneumatic Solenoid Valves:

Model
4V210-06
4V220-06
4V230C-06
4V230E-06
4V230P-06
4V210-08
4V220-08
4V230C-08
4V230E-08
4V230P-08
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/8''
In=Out=1/4'', Exhaust=1/8''
Orifice Size
25.00 mm2 (Cv=0.78)
18.00 mm2 (Cv=0.67)
30.00 mm2 (Cv=0.89)
18.00 mm2 (Cv=0.67)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa (21~114psi)
Proof Pressure
1.5MPa (215psi)
Temperature ℃
-5~50
Material of Body
Aluminum alloy
Max. frequency
5 cycle/sec
3 cycle/sec
5 cycle/sec
3 cycle/sec

Product Video of 4V210-08 Pneumatic Solenoid Valve:

Main dimension of 4V210-08 Pneumatic Solenoid Valve:

Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT

More Pneumatic Solenoid Valves for you to choose:

Brando is a Pneumatic Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The most common types are 2/2 way, 3/2 way, 5/2 way and 5/3 way. The valves can be single or double acting (one or two solenoids).


Brando Supply:
1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4M220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10


2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15


3. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08

Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPTAirtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPTAirtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPTAirtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT

*4V100 Pneumatic Valves *4V200 Pneumatic Valves *4V300 Pneumatic Valves *4V400 Pneumatic Valves

Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT Airtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPTAirtac Type Pneumatic Air Solenoid Valve 4V210-08-DC24V 1/4'' NPT

*5/2 Way Pneumatic Valve *5/3 Way Pneumatic Valve *2/2 Way Pneumatic Valve *Pneumatic Fast Fitting

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
