Type 6013 Direct Acting Plunger Solenoid Valve Space-saving Flange Connection For Medical Ventilator

This 6013 plunger solenoid valve with Space-saving flange connection. The direct-acting plunger valves of the D.EV series are designed for operation in machine construction, instrument engineering and pneumatics. The robust construction and compact design allow use even under harsh climatic and mechanical conditions. The fully welded body concept with a plunger guide tube and stopper provide for a highly leak-proof system.

Youtube Video of 6013 Solenoid Valve:

Technical Data:

Overall Deminsion:

Details:

Applications:

Lab and medical technology
In lab and medical technology the requirements placed on the media-contacting parts of the valves are especially high. Contaminations due to the material used and the production or assembly processes must be avoided in any case. The valve 6013 fulfils these requirements especially well. All mediacontacting parts are made of high-quality stainless steel. After completion of production the valve is cleaned in a special cleaning process, in which all residue is completely removed.

Inkjet printers
Industrial inkjet printers have an operating pressure of 1...5 bar. While the print head shoots the ink droplets onto the paper at approx. 5 bar, the upstream ink preparation and supply functions use a pressure of about 1.5 bar. Chemical resistance and flushability are necessary for trouble-free operation. The stainless steel versions of valve types 6011 and 6013 with highly resistant EPDM, FFKM as the seal material are optimal for performing this task.

Irrigation systems
Irrigation by means of sprinkler or hose systems is necessary for the natural growth of plants in soil. The irrigation takes place at regular intervals with a small quantity of water at a water pressure of 1~6 bar. To save electrical power during the irrigation intervals the switching valves 6013 are designed as energy-saving pulse versions. A short current pulse is sufficient to open or close the valves. This allows energy savings of up to 95 percent.

Features:

1. Valve 6013 is a direct-acting plunger valve up to diameter of DN 6.0.
2. The stopper and plunger guide tube are welded together to enhance pressure resist-ance and leak-tightness.
3. Various seal material combinations are available depending on the application.
4. The coils are moulded with polyamide or with chemically resistant epoxy.
