Findeva Type R Series Pneumatic Roller Vibrator For Silos
Findeva Type R Series Pneumatic Roller Vibrator For Silos
Findeva Type R Series Pneumatic Roller Vibrator For Silos
Findeva Type R Series Pneumatic Roller Vibrator For Silos
Findeva Type R Series Pneumatic Roller Vibrator For Silos
Findeva Type R Series Pneumatic Roller Vibrator For Silos
Findeva Type R Series Pneumatic Roller Vibrator For Silos
Findeva Type R Series Pneumatic Roller Vibrator For Silos
Specifications
Brand Name :
BRANDO
Model Number :
R-50, R-65, R-80, R-100, R-120
Certification :
CE, ISO
Place of Origin :
China, Ningbo
MOQ :
1 pc
Payment Terms :
L/C, T/T, Western Union, Paypal
Supply Ability :
200000 pcs per month
Delivery Time :
4 to 7 working days
Packaging Details :
Box, Carton, Pallet
Price :
Negotiation
Product Name :
Pneumatic Roller Vibrator
Rated Frequency :
10000 to 36000 RPM
Centrifugal Force :
1070 to 12500 N
Working Temperature :
up to 150℃
Description

Findeva Type R Series Pneumatic Roller Vibrator For Silos

R series Pneumatic Roller Vibrators are simply constructed high-frequency roller vibrators, wide range for many applications.

Properties:
1. High torque
2. Rated frequency 10000 to 36000 RPM
3. Centrifugal force 1070 to 12500 N
4.Continuously variable
5. Can be used up to 150°C
6. Resistant to extreme environmental conditions

Field of application:
1 Emptying of hoppers and chutes
2. Screen filters
3. Conveying of particulates
4. Preventing adhesions in pipelines and silos
5. Transporting of fine powders
6. Compacting of plastic and concrete in throughs

Main Dimension of R Series Pneumatic Roller Vibrators:

Findeva Type R Series Pneumatic Roller Vibrator For Silos

Model
A
(mm)
Width
(mm)
C
(mm)
D
(mm)
E
(mm)
F
(mm)
G
(mm)
H
(Thread)
R-50
50
29
86
68
12
7
40
G1/8''
R-65
65
37
113
90
16
9
50
G1/4''
R-80
80
43
128
104
16
9
60
G1/4''
R-100
100
52
160
130
20
11
80
G3/8''
R-120
120
77
194
152
24
17
-
G3/8''


Technical Data of R Series Pneumatic Roller Vibrators:

Model
Vibrations
(x1000 RPM)
Centrifugal Force
(N)
Air Consumption
(l/min)
2 bar
4 bar
6 bar
2 bar
4 bar
6 bar
2 bar
4 bar
6 bar
R-50
25.0
35.0
36.0
1070
2920
4220
100
145
195
R-65
19.0
21.0
26.0
2730
4830
6120
200
300
400
R-80
15.5
18.5
19.0
3000
6090
7450
290
430
570
R-100
11.0
14.0
16.0
3750
6750
8900
370
550
730
R-120
10.0
11.5
12.5
8000
10000
12500
500
730
970


Construction of R Series Pneumatic Roller Vibrators:

Findeva Type R Series Pneumatic Roller Vibrator For Silos

More Pneumatic Vibrators for your to choose:

Findeva Type R Series Pneumatic Roller Vibrator For Silos Findeva Type R Series Pneumatic Roller Vibrator For Silos Findeva Type R Series Pneumatic Roller Vibrator For Silos

GT Series

Pneumatic Turbine Vibrators

K Series

Pneumatic Ball Vibrators

R Series

Pneumatic Roller Vibrator

More Accessories for Pneumatic Vibratos:

Findeva Type R Series Pneumatic Roller Vibrator For Silos Findeva Type R Series Pneumatic Roller Vibrator For Silos
Pneumatic Fitting Pneumatic Silencer

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
