Nass Type 0545 110V AC 113-030-0279 113-030-0126 Solenoid Valve Coil

Because the wire diameter of the coil and the magnetic area of the magnetic steel directly affect the magnetic force of the solenoid valve coil, the dc coil can be removed from the core and move freely. The ac solenoid valve coil can not be pulled out from the iron core, once pulled out, will cause a surge in the coil current, seriously burned the coil. In addition, there is no need for any short circuit ring inside the dc coil core.

Solenoid valve coil magnetic force size, to a certain extent, determines whether the solenoid valve can operate normally. If the magnetic force is too large, the solenoid valve cannot operate. If the magnetic force is too small, the solenoid valve is not operational. The best way is to control solenoid valve coil magnetic force properly.​

Technical parameter of 0545 110-030 NASS Type Solenoid Valve Coil:

Main dimension of Nass Type 0545 Electronic Drain Solenoid Coils:

Phyical map of 113-030-0028 nass type electromagnetic coil:

Applicatoin of nass type 113-030-0035 electric magnetic coil:

More details about 0545 110-030 series Solenoid Coil can be found below the Youtube Video:

Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
