Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30
Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30
Specifications
Brand Name :
BRANDO
Model Number :
CXSWM, CXSWL
Certification :
CE, ISO
Place of Origin :
Ningbo, China
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
4-7 work days
Packaging Details :
Inner Box, Carton, Pallet
Cylinder Type :
Dual Rod Cylinder
Bore Size (mm) :
6, 10, 16, 20, 25, 32
Standard Stroke (mm) :
10, 20, 30, 40, 50, 75, 100, 125, 150, 175, 200
Max Operating Pressure :
0.7 Mpa
Cushion :
Rubber Bumper on both ends
Port Size :
M5x0.8, 1/8''
Bearing Type :
Slide Bearing, Ball Bushing Bearing
Piston Speed :
50 to 500mm/s
Description

Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30

Shop for dual rod guided pneumatic cylinders. Bore sizes range from 6mm to 32mm, and stroke options range from 10mm to 200mm. These double-acting pneumatic cylinders come with a magnet that is available with PT, NPT or G thread types.

To improve load performance, guided pneumatic actuators use guide rods that are installed parallel to the piston rod which provides non-rotating, high side stability. Like rodless cylinders, dual rod air cylinders reduce uneven seal wear, and piston and rod bending.

Specifications of CXSW Series Pneumatic Cylinder:

Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30

Stroke of CXSW Series Pneumatic Cylinder:

Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30


Ordering Code of CXSW Series Pneumatic Cylinder:
Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30

Theoretical Output of CXSW Series Pneumatic Cylinder:

Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30

Brando Supply Pneumatic Air Cylinders:

Airtac Type Pneumatic Cylinder Festo Type Pneumatic Cylinder SMC Type Pneumatic Cylinder
Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30 Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30 Dual Piston Double Rod Pneumatic Air Cylinder SMC Type CXSWM25-30

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
