Festo Type ADVU Series Compact Pneumatic Air Cylinders
Festo Type ADVU Series Compact Pneumatic Air Cylinders
Specifications
Brand Name :
BRANDO
Model Number :
ADVU
Certification :
CE, ISO
Place of Origin :
Ningbo, China
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
4-7 work days
Packaging Details :
Inner Box, Carton, Pallet
Product Series :
Compact Cylinder
Bore Size (mm) :
12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125
Standard Stroke (mm) :
5, 10, 15, 20, 25, 30, 40, 50, 60, 80
Acting Type :
Double Acting
End of Piston Rod :
Female Thread, Male Thread
Thread Sizes :
M3, M4, M5, M6, M8, M10, M12, M16, M10x1.25, M12x1.25, M16x1.5, M20x1.5, M27x2
Operating Medium :
Compressed Air
Description

Festo Type ADVU Series Compact Pneumatic Air Cylinders

Compact air cylinder, ADVU, AEVU:
1. Single-acting or double-acting cylinder with a wide range of mounting options.
2. 50% less installation space than comparable ISO cylinders to ISO 15552
3. Wide range of variants for customized applications
4. Piston rod with internal or external thread
5. Magnetic piston for position sensing


Technical Data of ADVU Series Compact Pneumatic Cylinder:

Festo Type ADVU Series Compact Pneumatic Air Cylinders

Festo Type ADVU Series Compact Pneumatic Air Cylinders

Stroke of ADVU Series Compact Pneumatic Cylinder:

Bore (mm) Standard Stroke (mm) Max. Std Stroke (mm)
ADVU 12 5 10 15 20 25 30 40 1 ~ 200
16 1 ~ 200
20 5 10 15 20 25 30 40 50 1 ~ 200
25 1 ~ 200
32 5 10 15 20 25 30 40 50 60 80 1 ~ 300
40 1 ~ 300
50 10 15 20 25 30 40 50 60 80 1 ~ 300
63 1 ~ 300
80 10 15 20 25 30 40 50 60 80 1 ~ 400
100 1 ~ 400
125 1 ~ 400
ADVULQ 12 5 10 15 20 25 30 40 1 ~ 200
16 1 ~ 200
20 5 10 15 20 25 30 40 50 1 ~ 200
25 1 ~ 200
32 5 10 15 20 25 30 40 50 60 80 1 ~ 300
40 1 ~ 300
50 10 15 20 25 30 40 50 60 80 1 ~ 300
63 1 ~ 300
80 10 15 20 25 30 40 50 60 80 1 ~ 400
100 1 ~ 400
125 1 ~ 400


Ordering Code of ADVU Series Compact Pneumatic Cylinder:


Festo Type ADVU Series Compact Pneumatic Air Cylinders

Brando Supply Pneumatic Air Cylinders:

Airtac Type Pneumatic Cylinder Festo Type Pneumatic Cylinder SMC Type Pneumatic Cylinder
Festo Type ADVU Series Compact Pneumatic Air Cylinders Festo Type ADVU Series Compact Pneumatic Air Cylinders Festo Type ADVU Series Compact Pneumatic Air Cylinders

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
