VFA3430-02 SMC Type Double Air Operated Pilot Valve 5 Way 3 Position
VFA3430-02 SMC Type Double Air Operated Pilot Valve 5 Way 3 Position
Specifications
Brand Name :
Brando
Model Number :
VFA3430-02
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
200000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Individual box, Carton, Pallet
Valve Type :
5 Way 3 Position
Port Size :
In=Out=1/4'', Exhaust=1/8''
Pressure Range :
0.15 to 0.9 MPa
Body Material :
Die-Cast Aluminum
Acting :
Exterior Control
Fluid :
Compressed Air
Lubrication :
Not Required
Ambient and Fluid Temperature :
-10 to +60℃ (No freezing)
Description

VFA3430-02 SMC Type Double Air Operated Pilot Valve 5 Way 3 Position

Air Pilot Valve Features:


1. Good tightness and sensitive reaction;
2. Three position with three kinds of central function for your choice;
3. Internal hole adopts special processing technology which has little attrition friction, low start pressure and long service life.
4. Integrate with the manifold to save installation space.
5. Single valve or multiple manifold mounted valve applications
6. Finally a compact design with maximum flow.

Specifications of VFA Series Air Pilot Valves:

Fluid Air
Operating Pressure Range 2 position single 0.15 to 0.9 MPa
2 position double 0.1 to 0.9 MPa
3 position 0.15 to 0.9 MPa
Pilot Pressure Range 2 position single (0.4xP+0.1) to 0.9 MPa: Operating pressure range
2 position double 0.1 to 0.9 MPa
3 position 0.15 to 0.9 MPa
Ambient and Fluid Temperature -10 to +60℃ (No freezing)
Lubrication Not required
Mounting Orientation Free
Impact/Vibration Resistance 300/50 (m/s²)

Ordering Code of VFA Series Air Pilot Valves:

VFA3430-02 SMC Type Double Air Operated Pilot Valve 5 Way 3 Position

Flow Characteristics of VFA Series Air Pilot Valves:

VFA3430-02 SMC Type Double Air Operated Pilot Valve 5 Way 3 Position


Dimension of VFA Series Air Pilot Valves:

VFA3430-02 SMC Type Double Air Operated Pilot Valve 5 Way 3 Position

Production Video of BRANDO Pneumatic Valves:

More Pneumatic Products for you to choose:

2/2 Way Pneumatic Valves 3/2 Way Pneumatic Valves 5/2 Way Pneumatic Valves 5/3 Way Pneumatic Valves
Namur Solenoid Valves Air Pilot Valves Pneumatic Cylinders Silencers and Fittings
VFA3430-02 SMC Type Double Air Operated Pilot Valve 5 Way 3 Position VFA3430-02 SMC Type Double Air Operated Pilot Valve 5 Way 3 PositionVFA3430-02 SMC Type Double Air Operated Pilot Valve 5 Way 3 Position

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
