Sub Base Brass Solenoid Valve 6013 A 1.5 2.0 2.5 3.0 4.0 NBR EPDM FKM FLNSCH
Sub Base Brass Solenoid Valve 6013 A 1.5 2.0 2.5 3.0 4.0 NBR EPDM FKM FLNSCH
Sub Base Brass Solenoid Valve 6013 A 1.5 2.0 2.5 3.0 4.0 NBR EPDM FKM FLNSCH
Sub Base Brass Solenoid Valve 6013 A 1.5 2.0 2.5 3.0 4.0 NBR EPDM FKM FLNSCH
Specifications
Brand Name :
BRANDO
Model Number :
6013 FLNSCH
Certification :
CE, ISO
Place of Origin :
China, Ningbo
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
50000 pcs per month
Delivery Time :
4 to 7 working days
Packaging Details :
Inner Box, Carton, Pallet
Orifice Size :
1.5mm, 2mm, 3mm
Function :
2 Way Normally Closed
Operation :
Plunger Direct Acting
Body Material :
Brass
Seal Material :
NBR, EPDM, FKM
Voltage :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Description

Sub Base Brass Solenoid Valve 6013 A 1.5 2.0 2.5 3.0 4.0 NBR EPDM FKM FLNSCH

6013 is a direct-acting plunger solenoid valve. Various seal material combinations are available depending on the application. It is a cost-effective valve with a universal application for neutral and clean liquids, gases and vapors. A specific flange design (SFB) enables space-saving arrangement of valves on a manifold. The coils are moulded with polyamide or with chemically resistant epoxy.

Product Video of 6013 FLNSCH Brass Solenoid Valve:


Technical Data of 6013 FLNSCH Solenoid Valve:

Sub Base Brass Solenoid Valve 6013 A 1.5 2.0 2.5 3.0 4.0 NBR EPDM FKM FLNSCH

Model
Port Size
(Inch)
Orifice Size
(mm)
Kv
Pressure Range (bar)
Medium Temperature (℃)
Dimension
A
F
K
6013
1/8''
1.5
0.05
0 to 40
NBR: -10 to +80
EPDM: -30 to +120
FKM: -30 to +150
32
32
66
2
0.12
0 to 25
2.5
0.16
0 to 16
3
0.23
0 to 10
1/4''
1.5
0.05
0 to 40
46
32
70
2
0.12
0 to 25
3
0.23
0 to 10
4
0.3
0 to 4
5
0.35
0 to 2
6
0.55
0 to 1.5
Sub-base
(SFB)
1.5
0.1
0 to 40
32
32
66/68
2
0.15
0 to 25
3
0.23
0 to 10
