4V310-10-DC24V Airtac Type 5 Way Pneumatic Solenoid Valve 24V DC
4V310-10-DC24V Airtac Type 5 Way Pneumatic Solenoid Valve 24V DC
Specifications
Brand Name :
Brando
Model Number :
4V310-10
Certification :
CE
Place of Origin :
China
MOQ :
200 PCS
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
200000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Individual box, Carton, Pallet
Type :
5/2 Way, Single Solenoid
Port Size :
In=Out=3/8'', Exhaust=1/4''
Pressure Range :
0.15 to 0.8MPa (21 to 114PSI)
Max Pressure Resistance :
1.5MPa (215PSI)
Body Material :
Aluminum Alloy
Max. Frequency :
5 Cycle / Second
Description

4V310-10-DC24V Airtac Type 5 Way Pneumatic Solenoid Valve 24V DC

This 4V310-10 solenoid valve is the 3/8'' 5 way 2 Position Pneumatic Solenoid Valve. It is a switch for routing air to any pneumatic device, usually an actuator, allowing a relatively small signal to control a large device. It is also the interface between electronic controllers and pneumatic systems. This valve allows pneumatic control of position, flow, pressure and temperature.

Product Features:

1. 2 position 5 way solenoid valve whose working medium is air.
2. Outstanding safety grade of IP65 which makes it more safe to use.
3. The maximum pressure endurance is 1.5MPa (215PSi), very durable.
4. The air is filtrated by a 40μm filtration net to provide better working performance.
5. The solenoid valve body is made of new aluminum alloy material, which has strong pressure resistance, good corrosion resistance and fast heat dissipation.

Data of 4V300 Series Pneumatic Solenoid Valves:

Model
4V310-08
4V320-08
4V330C-08
4V330E-08
4V330P-08
4V310-10
4V320-10
4V330C-10
4V330E-10
4V330P-10
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/4''
In=Out=3/8'' Exhaust=1/4''
Orifice Size
25.00 mm2 (Cv=1.40)
18.00 mm2 (Cv=1.00)
30.00 mm2 (Cv=1.68)
18.00 mm2 (Cv=1.00)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa(21~114psi)
Proof Pressure
1.5MPa(215psi)
Temperature ℃
-20~70
Material of Body
Aluminum alloy
Max. frequency
4 cycle/sec
4 cycle/sec
4 cycle/sec
4 cycle/sec


Dimension of 4V310-10 Pneumatic Solenoid Valve:

4V310-10-DC24V Airtac Type 5 Way Pneumatic Solenoid Valve 24V DC

Product video of 4V310-10 Pneumatic Solenoid Valve:


Production Video of Pneumatic Solenoid Valve:

More Pneumatic Products for you to choose:

4V310-10-DC24V Airtac Type 5 Way Pneumatic Solenoid Valve 24V DC4V310-10-DC24V Airtac Type 5 Way Pneumatic Solenoid Valve 24V DC4V310-10-DC24V Airtac Type 5 Way Pneumatic Solenoid Valve 24V DC4V310-10-DC24V Airtac Type 5 Way Pneumatic Solenoid Valve 24V DC

Solenoid Operator Manifold Silencer Pneumatic Hose Fittings

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
