Male Y Brass Pneumatic Quick Connect Coupling 1/8'' 1/4'' 3/8'' 1/2''
Male Y Brass Pneumatic Quick Connect Coupling 1/8'' 1/4'' 3/8'' 1/2''
Specifications
Brand Name :
BRANDO
Model Number :
BCKH-3U-Z
Certification :
CE, ISO
Place of Origin :
Ningbo, China
MOQ :
5 pcs
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability :
10000000pcs per month
Delivery Time :
1 week after payment
Packaging Details :
PVC bag, then inner box, then carton, then pallet
Product Name :
Pneumatic Hose Fittings
Type :
Male Y
Tube OD (Inch) :
1/8", 1/4", 3/8", 1/2"
Tube OD (Mertric) :
4mm, 6mm, 8mm, 10mm, 12mm
Material :
Brass
Working Pressure Range :
0 to 0.8MPa
Working Temperature :
0 to +60℃
Connection :
Push On
Description

Male Y Brass Pneumatic Quick Connect Coupling 1/8'' 1/4'' 3/8'' 1/2''

Pneumatic push in fittings, also called push to connect fittings, provide a leak-free means of easily connecting hoses in your compressed air system. Fittings can have between 1-6 inlet/outlet ports or may have additional functionality such as an integrated pressure gauge or silencer.

The greatest advantage of push in fittings is the quick release system which allows for simple and easy installation by hand, eliminating the need for tools and adhesive. Due to the ease of connecting and disconnecting air lines, it allows for frequent changing of air lines at a low cost. They are offered in a wide range of tube sizes, connections, and thread combinations to suit the desired outcome.

Technical data of Pneumatic Hose Fittings:

Material
Plastic / Brass
Threaded Connection
BSP
BSPP
Metric Thread
NPT
Working Pressure
0 to 0.8MPa
Connecting Tube
PA
PU
Connecting Diameter Tube
3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 16mm (Outer Diameter)
Medium
Compressed Air
Working Temperature
~60℃

Specifications of Male Y Brass Pneumatic Hose Fittings:

Male Y Brass Pneumatic Quick Connect Coupling 1/8'' 1/4'' 3/8'' 1/2''

Model No
D
M
L1
L2
L
E
S
BCKH-3U-Z2.5
4
M5X0.8
6
4
39
12
10
BCKH-3U-Z4
6
M8X1
7
4
41
12
M10X1
7
4
42
13
G1/8''
6
4
41
12
G1/4''
8
5
43
14
G3/8''
6
4
41
17
G1/2''
8
5
43
22
BCKH-3U-Z6
8
M10X1
7
4
44
14
13
G1/8''
6
5
43
12
G1/4''
8
5
45
14
G3/8''
9
5
47
17
G1/2''
10
5
48
22
BCKH-3U-Z8
10
M12X1.25
9
5
49
17
15
G1/8''
6
5
46
14
G1/4''
8
5
48
14
G3/8''
9
5
50
17
G1/2''
10
6
51
22
BCKH-3U-Z10
12
M16X1.5
10
5
53
19
19
G1/8''
6
5
48
16
G1/4''
8
5
50
16
G3/8''
9
5
52
17
G1/2''
10
6
53
22

Product Video of BRANDO Brass Pneumatic Hose Fittings:


List of All Push To Connect Brass Pneumatic Hose Fittings:

Male Y Brass Pneumatic Quick Connect Coupling 1/8'' 1/4'' 3/8'' 1/2''

Choosing the Right Fittings for Your Pneumatic System:

Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting

Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
