3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector
3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector
3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector
3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector
3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector
3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector
Specifications
Brand Name :
BRANDO
Model Number :
DMF-Z-76S
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union, L/C, MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Inner Box,Carton,Pallet
Product Name :
BFEC Pulse Jet Valve
Valve Type :
Right Angle (Threaded)
Port Size :
3''
Coil Voltage :
24VDC, 220VAC
Diaphragm Material :
NBR
No of Diaphragm :
2
Description

3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector

Dust Collector Pulse Jet Valve is specially designed for use in dust collector systems. BRANDO make available for our clients a comprehensive gamut of Dust Collector Solenoid Valve. Our pulse jet valves are used for pulsing large volumes of air into filter bags for particulate removal. The body and bonnet of these valves are constructed using aluminum pressure die cast. Moreover, the pressure rangeof these valves is 0.3 bar to 0.8 MPa. The design offers extremely high flow, simple installation, and easy maintenance. In operation, a unique patented flow path results in a large per-pulse volume. BRANDO also supply valve diaphragm, solenoid valve coil and solenoid valve armature assembly.


Technical Data of Z series Right Angle Pulse Jet Valves:

Model
Nominal diametrer
Number of diaphragms
Inlet
Outlet
Weight (kg)
mm
inch
DMF-Z-20
Φ20
3/4''
1
3/4''
3/4''
0.65
DMF-Z-25
Φ25
1'''
1
1''
1''
0.8
DMF-Z-40S
Φ40
1 1/2''
2
1 1/2''
1 1/2''
1.4
DMF-Z-50S
Φ50
2''
2
2''
2
2.4
DMF-Z-62S
Φ62
2 1/2''
2
2 1/2''
2 1/2''
3.5
DMF-Z-76S
Φ76
3''
2
3''
3''
4.3
DMF-Z-90S
Φ90
3 1/2''
2
3 1/2''
3 1/2''
5.75
DMF-Z-102S
Φ102
4''
2
4''
4''
7.3
DMF-20L-B
Φ20
3/4''
1
3/4''
Φ27
0.75

Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.

Dimension of DMF-Z-76S BFEC Pulse Jet Valve:

3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector

Video of BFEC DMF-Z-76S Pulse Jet Valve:


More BFEC Pulse Valve For You to Choose:

3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector

Right Angle Type Quick Mount Type Submerged Type

3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector 3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector 3 Inch DMF-Z-76S BFEC Pulse Jet Valve For Dust Collector

Diaphragm Solenoid Coil Armature Assembly Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
