1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector
1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector
Specifications
Brand Name :
BRANDO
Model Number :
CA15T
Certification :
ISO,GB,CE
Place of Origin :
CHINA NINGBO
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union, L/C
Supply Ability :
10000pcs per month
Delivery Time :
4 to 7 days
Packaging Details :
Inner Box,Carton,Pallet
Port Size :
1/2''
Valve Series :
T
Valve Structure :
Right Angle, Threaded Port
Diaphragm Material :
NBR, FKM
Workinｇ Pressure Range :
0.35 To 0.85 MPa
Coil Voltage :
24VDC, 110VAC, 220VAC
Description

1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector

T series threaded pulse jet valves are high-performance reverse pulse jet valves. The diaphragm valves with threaded ports are designed for the filter cleaning of dust collectors and baghouses in reverse pulse jet systems. Pulse Jet Valve, also called diaphragm valve acts as a "switch" for compressed air in the dust collector system for bag filters. It is controlled by the electric signals from the Pulse Controller. Pulse Jet Valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. Pulse jet valves are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.

Technical Data of T Series Pulse Jet Valves:

Model No
CA15T
CA20T
CA25T
CA35T
CA45T
CA50T
CA62T
CA76T
Office Size
(mm)
15
20
25
35
45
50
62
76
Port Size
(Inch)
1/2''
3/4''
1''
1 1/2''
1 1/2''
2''
2 1/2''
3''
Diaphragm Number
1
2
Working pressure
0.35 to 0.85 MPa (5 to 125 PSI)
Voltage
24VDC, 24VAC, 110VAC, 220VAC
Diaphragm Material
NBR, FKM, EPDM
Body Material
Aluminum Alloy
Valve Structure
Right Angle (Outlet is at 90° to Inlet), Threaded Port

Ordering Code of T Series Pulse Jet Valve:

1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector


Main Dimension of CA15T Pulse Jet Valve:

1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector

Video of CA15T Pulse Jet Valve:

More Goyen Type Pulse Valves for you to choose:

1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector 1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector 1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector 1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector
T Series DD Series FS Series MM Series
1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector 1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector 1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector 1/2'' CA15T Goyen Type Pulse Jet Solenoid Valve For Dust Collector
RCA Series Solenoid Coil Solenoid Armature Diaphragm


Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
