1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC
1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC
Specifications
Brand Name :
Brando
Model Number :
321H35, 321H36
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
4-8 days
Packaging Details :
Inner boxes, Carton, Pallet
Working Medium :
Water, Air, Gas
Port Size :
1/2'', 3/4''
Orifice Size :
15mm
Operation Mode :
2 Way, Normally Closed
Operation :
Diaphragm Pilot Operated
Body Material :
Brass
Pressure Range :
1.5 to 50 Bar
Voltages :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Description

1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC

2-Way Normally Closed 1/2'' Solenoid Valves are used in a wide variety of applications with or without pressure differential. Ideally suited for air, liquids and gases, these valves are mainly available with brass or stainless steel body associated to a large range of sealing materials offering vast chemical compatibilities .

Markets:
• Beverage
• Life Science
• Industrial Equipment

Technical Data of High Pressure Solenoid Valve:​

Port Size
1/2'', 3/4''
Orifice Size
15mm
Function
2 Way, Normally Closed
Operation
Diaphragm Pilot Operated
Working Medium
Water, Air, Gas
Working Pressure Range
1.5 to 50 Bar
Voltages
12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)


Main Dimension of High Pressure Solenoid Valve:

1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC

Brando Solenoid Valve Factory Production Video:


More High Pressure Solenoid Valves for you to choose:

Brass Solenoid Valves
1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC
MAX 50 bar MAX 50 bar MAX 50 bar MAX 50 bar
1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC
MAX 50 bar MAX 70 bar MAX 120 bar MAX 200 bar

Stainless Steel Solenoid Valves
1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC
MAX 50 bar MAX 50 bar MAX 50 bar MAX 100 bar
1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC 1/2'' 321H35 2/2 Way NC High Pressure Solenoid Valve 24VDC 220VAC
MAX 120 bar MAX 160 bar MAX 200 bar MAX 300 bar

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
