Specifications
Brand Name :
Brando
Model Number :
5531-04
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
$3 to $8 per pc
Payment Terms :
L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
4-8 days
Packaging Details :
Inner boxes, Carton, Pallet
Product Name :
5531 Solenoid Valve
Working Fluids :
Coal Gas, Natural Gas
Port Size :
1/8'' (G, NPT)
Orifice Size :
DN2.0
Voltages :
12VDC, 24VDC, 24VAC, 110VAC, 115VAC, 120VAC, 220VAC, 230VAC, 240VAC
Operation :
Direct Acting
Operation Mode :
3 Way / 2 Way, Normally Closed / Normally Open
Body Material :
Brass
Seal Material :
VITON
Temperature :
-30 to +150℃
Pressure Range :
0 to 6.0bar
Description

Natural Coal Gas Adjustable Flow Solenoid Valve 5531 220V AC 24V DC

Product Features:

1. Operation: Direct Acting, 3 Way / 2 Way, Normally Closed / Normally Open.

2. Application Examples: Coffee Machine, Electric Steam Iron, Steam Cleaner.

3. Wide Voltages Supply: DC: 12V, 24V, AC: 24V, 120V, 240V (60Hz), 110V, 220V (50Hz).

4. Applied to low pressure system,open from 0 bar.

Dimension & Technical Data of Brass Solenoid Valves:

Natural Coal Gas Adjustable Flow Solenoid Valve 5531 220V AC 24V DC

Model
5531-04
Medium
Coal Gas, Natural Gas
Medium Temperature
-30 to +150℃
Pressure Range
0 to 6.0 bar
Port Size
1/8'' (G, NPT)
Orifice Size
DN2.0
Seal Material
FKM

Natural Coal Gas Adjustable Flow Solenoid Valve 5531 220V AC 24V DC

Model
5531-03
Medium
Coal Gas, Natural Gas
Medium Temperature
-30 to +150℃
Pressure Range
0 to 6.0 bar
Port Size
1/8'' (G, NPT)
Orifice Size
DN2.8

Adjustable: DN0.75, 1.0, 1.35

Seal Material
FKM

Natural Coal Gas Adjustable Flow Solenoid Valve 5531 220V AC 24V DC

Model
5524
Medium
Hot water, Air , Oil, Steam
Medium Temperature
-30 to +150℃
Pressure Range
0 to 10.0 bar
Port Size
Inlet: 1/8'' (G, NPT),
Outlet: OD φ7.5mm
Orifice Size
DN2.3
Seal Material
FKM

Natural Coal Gas Adjustable Flow Solenoid Valve 5531 220V AC 24V DC

Model
5515-08
Medium
Hot water, Air , Oil, Steam
Medium Temperature
-30 to +150℃
Pressure Range
0 to 20.0 bar
Port Size
1/8'' (G, NPT)
Orifice Size
DN1.0, 1.5, 2.0, 2.6
Seal Material
FKM


More Solenoid Valves for you to choose:

Natural Coal Gas Adjustable Flow Solenoid Valve 5531 220V AC 24V DCNatural Coal Gas Adjustable Flow Solenoid Valve 5531 220V AC 24V DC

Natural Coal Gas Adjustable Flow Solenoid Valve 5531 220V AC 24V DCNatural Coal Gas Adjustable Flow Solenoid Valve 5531 220V AC 24V DC

Brando Factory Production of Brass Solenoid Valves:


As a solenoid valve supplier, BRANDO supplys general purpose solenoid valve for general mediums control. Such as water, air, gas, oil. Offering the cost-effective solution for your projects. Available in brass, stainless steel and PVC material for your projects.
● Size Range: 1/4" to 2" (1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4")
● Voltage: 12 Volt DC, 24 Volt DC, 24 Volt AC, 110 Volt AC, 220 Volt AC
● Pressure: 0-10 bar / 0.3-16 bar
● Temperature: -10℃~180℃
● Material: Brass, Stainless Steel and PVC
● Structure: Direct Acting / Diaphragm / Pilot Operated
● Function: Normally Closed / Normally Open
● Connection Type: Threaded, Flanged, Tri Clamp
● Tolerance: ±10%
