3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC
3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC
Specifications
Brand Name :
BRANDO
Model Number :
321H36
Certification :
CE, ISO
Place of Origin :
China, Ningbo
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
100000 pcs per month
Delivery Time :
4-8 days
Packaging Details :
Inner boxes, Carton, Pallet
Working Medium :
Water, Air, Gas
Port Size :
3/4''
Orifice Size :
15mm
Function :
2 Way, Normally Closed
Operation :
Diaphragm Pilot Operated
Body Material :
Brass
Pressure Range :
1.5 to 50 Bar
Voltages :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Description

3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC

These solenoid valves specially designed for high pressure applications (maximum 50 bar). The life expectancy of several millions of cycles, with response time of few milliseconds, allows the use of these valves on intensive applications and on high technology, as the plastic bottle blowing machines, or the laser cutting machines.

Product Features:
1. Model No: 321H35, 321H36 (Normally Closed); 322H35, 322H36 (Normally Open)
2. Port Size: 1/2'', 3/4''
3. Orifice Size: 15mm
4. Working Medium: Air, Water, Gas, etc
5. Working Pressure: 1.5 to 50 bar
6. Body Material: Brass
7. Operation: Diaphragm Pilot Operated
8. Function: 2 Way Normally Closed, 2 Way Normally Open
9. Coil Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Video of 321H35, 321H36:

Technical Data:​

3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC

Model No (Normally Closed)
321H35
321H36
Model No (Normally Open)
322H35
322H36
Port Size
1/2''
3/4''
Orifice Size
15mm
Function
2 Way Normally Closed, 2 Way Normally Open
Operation
Diaphragm Pilot Operated
Working Medium
Water, Air, Gas
Working Pressure Range
1.5 to 50 Bar
Voltage
12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)


Main Dimension:

3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC

Model No
A
B
C
D
L
H
J
K
M
321H35
1/2''
φ15
27
15
75
101
72
19
53
321H36
3/4''
φ19
32
15
82
107
72
19
53

BRANDO Solenoid Valve Factory Production Video:


More High Pressure Solenoid Valves for you to choose:

Brass Solenoid Valves
3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC
MAX 50 bar MAX 50 bar MAX 50 bar MAX 50 bar
3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC
MAX 50 bar MAX 70 bar MAX 120 bar MAX 200 bar

Stainless Steel Solenoid Valves
3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC
MAX 50 bar MAX 50 bar MAX 50 bar MAX 100 bar
3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC 3/4'' 321H36 Parker Type Solenoid Valve High Pressure 40 Bar 24VDC 220VAC
MAX 120 bar MAX 160 bar MAX 200 bar MAX 300 bar

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
