TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic
TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic
Specifications
Brand Name :
BRANDO
Model Number :
TN16X20S
Certification :
CE, ISO
Place of Origin :
Ningbo, China
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
4-7 work days
Packaging Details :
Inner Box, Carton, Pallet
Product Series :
Twin Rod Cylinder
Body Material :
Aluminum Alloy
Bore Size :
10mm, 16mm, 20mm, 25mm, 32mm
Standard Stroke :
10mm to 200mm
Acting Type :
Double Acting
Operating Pressure Range :
0.1 To 1.0 MPa
Proof Pressure :
1.5 MPa
Description

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic

Shop for dual rod guided air cylinders. Bore sizes range from 10mm to 63mm, and stroke options range from 10mm to 250mm. These double-acting pneumatic cylinders come with a magnet that is available with PT, NPT or G thread types.

To improve load performance, guided pneumatic actuators use guide rods that are installed parallel to the piston rod which provides non-rotating, high side stability. Like rodless cylinders, dual rod air cylinders reduce uneven seal wear, and piston and rod bending.


Specifications of TN Series Twin Rod Pneumatic Cylinder:

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic

Stroke of TN Series Twin Rod Pneumatic Cylinder:

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic


Ordering Code of TN Series Twin Rod Pneumatic Cylinder:
TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic

Criteria for selection: Cylinder thrust:

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic

Inner Structure of TN Series Twin Rod Pneumatic Cylinder:

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic

Brando Supply Pneumatic Air Cylinders:

Airtac Type Pneumatic Cylinder Festo Type Pneumatic Cylinder SMC Type Pneumatic Cylinder
TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic

Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
