3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator
3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator
Specifications
Brand Name :
Brando
Model Number :
Q614
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
50000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Inner boxes, Carton, Pallet
Structure :
Ball
Power :
Pneumatic
Pipe Connection :
Female Thread
Body Material :
Cast Steel, SS304, SS316
Seal Material :
PTFE, TFM
Working Medium :
Neutral Gas, Air
Port Size :
1/2'' to 2''
Way Number :
3 Way
Flow Direction :
L Pattern, T Pattern
Medium Temperature :
PTFE: -20 to +180℃, TFM: -30 to +230℃
Description

3 Way Pneumatic Ball Valve With Actuator Solenoid Valve Limit Switch

A pneumatic actuated ball valve uses compressed air to automate the control of media. Pneumatic actuated ball valves don’t rely on a motor, but they do require electricity when paired with an integral pilot or solenoid valve.

Here’s a breakdown of the components:

Pneumatic: Refers to the use of pressurized air or gas to create energy.
Actuator: The component that is used to automate control of the ball valve.
Ball Valve: A quarter-turn on/off valve that controls flow of media via a pivoting ball

Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN

Flow Direction of 3 Way Pneumatic Ball Valve:

3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator

Main Dimension of Pneumatic Ball Valve:

3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator

3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator

More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator 3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator 3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator 3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator
3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator 3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator 3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator 3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator
Pneumatic Butterfly Valves
3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator 3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator 3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator 3 Way Stainless Steel Air Operated Ball Valve With Pneumatic Actuator

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
