2 Inches Electric Brass Solenoid Valve Water Normally Closed 24V 220V
2 Inches Electric Brass Solenoid Valve Water Normally Closed 24V 220V
Specifications
Brand Name :
Brando
Model Number :
2W500-50
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
4-8 days
Packaging Details :
Inner boxes, Carton, Pallet
Port Size :
2''
Orifice Size :
50mm
Operation Mode :
2 Way Normally Closed
Action :
Direct Lifting Diaphragm
Working Fluids :
Air, Water, Oil, Gas
Body Material :
Brass
Seal Material :
NBR
Voltages :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Pressure Range :
0 to 1 MPa
Temperature Range :
-5 ℃ to +80 ℃
Description

2 Inches Electric Brass Solenoid Valve Water Normally Closed 24V 220V

Product Features:

1. Function: 2 Way Normally Closed, 2 Way Normally Open
2. Operation: Direct Lifting Diaphragm
3. Port Sizes: 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'', etc;
4. Orifice Sizes: 15mm, 20mm, 25mm, 35mm, 40mm, 50mm
5. Working Medium: Water, Air, Gas, Oil, etc.

6. Valve Body Material: Brass, Stainless Steel
7. Valve Seal Material: NBR, EPDM, FKM;
8. Solenoid Coil Voltages: 12VDC 24VDC, 24VAC, 110VAC, 220VAC, etc;
9. Solenoid Coil Protection Class: IP65, IP67, Ex Proof, etc;

Ordering Code of Brass Solenoid Valve:

2 Inches Electric Brass Solenoid Valve Water Normally Closed 24V 220V

Technical Data of Solenoid Valve:

Model
2W160-10
2W160-15
2W200-20
2W250-25
2W350-35
2W400-40
2W500-50
2W160-10-NO
2W160-15-NO
2W200-20-NO
2W250-25-NO
2W350-35-NO
2W400-40-NO
2W500-50-NO
Port Size
3/8''
1/2''
3/4''
1''
1 1/4''
1 1/2''
2''
Orifice Size
16
20
25
35
40
50
Cv Value
4.8
4.8
12
24
29
48
Medium
Air, Water, Oil, Gas
Action
Direct Lifting Diaphragm
Function
2 Way, Normally Closed (NC), Normally Open (NO)
Viscocity
20 cst Below
Pressure
Air: (1 to 1MPa), Water (0 to 0.7MPa), Oil (0 to 0.9MPa), Normally Open (0 to 0.8MPa)
Temperature
NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -5 to +150℃, Silicone: -15 to +150℃
Body Material
Brass
Voltages
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Coil Type
Waterproof Coil, Round Coil, Square Coil, etc.

Main Dimension of Solenoid Valve:

2 Inches Electric Brass Solenoid Valve Water Normally Closed 24V 220V

Model
Port Size
A
B
C
2W160-10
3/8''
66
56
103
2W160-10-NO
125
2W160-15
1/2''
66
56
103
2W160-15-NO
125
2W200-20
3/4''
73
56
110
2W200-20-NO
132
2W250-25
1''
98
73
117
2W250-25-NO
139
2W350-35
1 1/4''
118
93
160
2W350-35-NO
180
2W400-40
1 1/2''
118
93
160
2W400-40-NO
180
2W500-50
2''
156
124
188
2W500-50-NO
209


Solenoid Valve Assembly Display:

2 Inches Electric Brass Solenoid Valve Water Normally Closed 24V 220V 2 Inches Electric Brass Solenoid Valve Water Normally Closed 24V 220V

Brando Factory Production of Brass Solenoid Valves:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
