AirTAC 1/2'' Pneumatic Solenoid Valve 4V420-15 Double Coil 24V DC
AirTAC 1/2'' Pneumatic Solenoid Valve 4V420-15 Double Coil 24V DC
Specifications
Brand Name :
BRANDO
Model Number :
4V420-15
Certification :
CE, ISO
Place of Origin :
China, Ningbo
MOQ :
100pcs
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
200000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Plastic bag, Box, Carton, Pallet
Product Name :
Pneumatic Solenoid Valve
Working Fluid :
Air
Port Size :
In=Out=Exhaust=1/2''
Valve Type :
Double Solenoid, 5 Way 2 Position
Operating Pressure :
0.15 To 0.8 MPa
Proof Pressure :
1.2MPa
Body Material :
Aluminum Alloy
Coil Voltages :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Description

AirTAC 1/2'' Pneumatic Solenoid Valve 4V420-15 Double Coil 24V DC

Pneumatic solenoid valves generally have a spool design. They consist of an aluminum body with a cylindrical hole. The different ports of the valve connect to the cylinder. A sliding spool in the cylinder has several seals along its length. By sliding the spool back and forth through the cylinder, different ports can be connected or closed off. Pneumatic solenoid valves are appointed with two numbers. The first number shows how many ports the valve has, and the second number is the amount of states. For example, a 2/2-way valve has two ports (in/out) and two states (open/closed). A 5/2-way valve has five ports and two states. Directional valves usually have two, three, or five ports.

Directional control valves are used in pneumatic systems to direct or stop the flow of compressed air or oil to their equipment. They are probably the most commonly used components in pneumatic systems, such as those used to drive cylinders, larger industrial valves or pneumatic tools. The valve can have two or more ports and can perform various circuit functions. The directional control valve can be operated in different ways, such as manual operation or solenoid operation.

Technical Data of 4V400 Series Solenoid Valve:

Model
4V410-15
4V420-15
4V430C-15
4V430E-15
4V430P-15
Fluid
Air (to be filtered by 40μm filter element)
Acting
internal pilot or external pilot
Port Size
in=out=exhaust=1/2''
Orifice Size
4V410-15, 4V420-15: 48.0mm² (Cv=2.82)
4V430C-15: 40.0mm² (Cv=2.35)
Valve Type
5 way 2 position
5 way 3 position
Operating Pressure
0.15 to 0.8 MPa (21 to 114 psi)
Proof Pressure
1.2MPa (175psi)
Temperature
-20 to 70℃
Body Material
Aluminum Alloy
Max Frequency
3 cycle/sec
Voltages
12VDC, 24VDC, 24VAC, 110VAC, 220VAC


Main Dimension of 4V420-15 Solenoid Valve:

AirTAC 1/2'' Pneumatic Solenoid Valve 4V420-15 Double Coil 24V DC

Video of 4V420-15 Solenoid Valve:

Production Video of Pneumatic Valve:

More Pneumatic Products for you to choose:

Pneumatic Solenoid Valve Air Pilot Pneumatic Valve Push Pull Air Valve Hand Level Air Valve
Pneumatic Food Pedal Valve Pneumatic Hose Fitting Filter Regulator Lubricator Pneumatic Cylinder

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
