192 L/Min Plastic Pneumatic Diaphragm Pump Sand Mill Air Diaphragm Pump

Pneumatic Diaphragm Pump ​Application and Advantage:

Pneumatic diaphragm pumps are operated with compressed air . diaphragm pumps is suitable for pumping fluids with particles, and various liquids, which are highly viscous, volatile, corrosive or toxic, as well as colloids. The pump body is made of aluminum alloys, cast iron or stainless steel. The diaphragm is made of high quality rubber such as Nitrile rubber, chloronorgutta rubber, fluoroine rubber. The diaphragm pumps are widely used in the petroleum chemical, electronic, ceramic, food and textile industries

Pneumatic Diaphragm Pump Parameters

Flow Rate

About AODD Pneumatic Diaphragm Pump

If you're looking for a single pump that can be used in a wide variety of applications, you want an air-operated double diaphragm (AODD) pump. bogen provides the most complete line of AODD pumps available from one source. No other manufacturer offers more AODD pumps – or more size and flow options – that meet every sanitary standard, including FDA, USDA, 3A and EHEDG.

It is a positive displacement pump with the volume change caused by the reciprocating deformation of the diaphragm. Its working principle is similar to that of the plunger pump. Due to the characteristics of the working principle of the diaphragm pump, the diaphragm pump has the following characteristics:

(1) The pump will not overheat: driven by compressed air and motor, it is a process of expansion and heat absorption during exhaust. The temperature of the pneumatic pump is reduced during operation, and no harmful gas is discharged.

(2) No electric spark: the pneumatic diaphragm pump is not powered by electricity, and electrostatic spark is prevented after grounding.

(3) It can pass through liquid containing particles: it is not easy to be blocked because it works in a positive displacement mode and the inlet is a ball valve.

(4) The shear force on materials is very low: how to suck in and how to spit out during work, so the agitation of materials is less, which is suitable for the flying transportation of unstable substances.

(5) The flow can be adjusted. A throttle valve can be installed at the material outlet to adjust the flow.

(6) It has the function of self absorption.

(7) It can run empty without danger.

(8) Can dive into the water

(9) It can transport a wide range of fluids, from low viscosity to high viscosity, from corrosive to viscous.

(10) No complex control system, no cables, fuses, etc. (pneumatic diaphragm pump)

(11) Small size, light weight, easy to move.

(12) It will not pollute the working environment due to dripping.

(13) The pump can always maintain high energy and will not be reduced due to wear.

(14) 99.9% energy utilization. When the outlet is closed, the pump will stop automatically, and the equipment will move, wear, overload and heat. When the outlet is opened, the pump will start automatically (pneumatic diaphragm pump)

(15) No dynamic seal, easy maintenance to avoid leakage, no dead point during operation.
