Specifications
Brand Name :
XINCHENG
Model Number :
1.0*12m
Certification :
CCS,LR,BV
Place of Origin :
Qingdao
MOQ :
1piece
Price :
$200-6000/piece
Payment Terms :
Western Union, MoneyGram, T/T, L/C
Supply Ability :
150PCS per month
Delivery Time :
15days
Packaging Details :
deflated by tray
Length :
5.0m-20m,from 1000mm to 24000mm
Color :
Black
Diameter :
1.8m
Packing :
Standard Package,Pallet Package for Ship Launching Airbag
Warranty period :
24 months
Technology :
High Pressure
Working pressure :
0.05MPa to 0.15Pa
Description

Cylindrical Shape High Pressure Air Bags , Inflatable Airbag Launch

Marine Airbag for ship launching have the best designed structure which consists of three different functional membranes in rubber layers.

1) Outer Rubber Layer

The outer rubber layer that covers the outside of marine airbag to protect under layers from abrasion and other external forces. This compound has sufficient tensile and tearing strength to withstand any condition and hard usage.

2) Inner Rubber Layer

The inner rubber layer seals pressurized air inside marine airbags.

3) Synthetic-Tire-Cord Layer as Reinforcement

The reinforcement cord layers, which are made of synthetic-tire-cord commonly used in tires, are arranged at ideal angles to hold the internal pressure and distribute stress evenly. So they can provide strong efficient reinforcement.

The approximate bearing capacity can be calculated as follows:

F=PS

S=π x (D1-D2)/2

Mark:

F: Bearing capacity

P: Inner pressure

S: Contact area

D1: Diameter of airbags when free of loat

D2: Working height of airbags when loaded

Some normal sizes of our marine airbags, other sizes are also available
Diameter(m)
Effective Length(m)
Layer
Pressure(MPa)
1.0
10
5~6
0.07~0.10
1.0
12
5~6
0.07~0.10
1.0
15
5~6
0.07~0.10
1.2
10
5~6
0.08~0.12
1.2
12
5~6
0.08~0.12
1.2
15
5~6
0.08~0.12
1.5
12
5~8
0.08~0.16
1.5
15
5~8
0.08~0.16
1.5
18
5~8
0.08~0.16
1.5
20
4~8
0.08~0.16
1.5
24
5~8
0.08~0.16
1.8
12
5~8
0.08~0.15
1.8
15
5~8
0.08~0.15
1.8
18
5~8
0.08~0.15
1.8
20
5~8
0.08~0.15
1.8
24
5~8
0.08~0.15
2.0
18
6~10
0.08~0.18
2.0
20
6~10
0.08~0.18
2.0
24
6~10
0.08~0.18
2.5
18
7~10
0.07~0.13
2.5
20
7~10
0.07~0.13
2.5
24
7~10
0.07~0.13

airbag features
1. Big carrying capacity
2. High capacity against compression and twisting
3. New design of anti-bursting contruction at the end
4. Optimized structural layout
5. Durable aging resistance and anti-wear characteristic
6. Higher flesibility and damping capacity.
