3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire
3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire
3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire
3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire
3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire
3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire
3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire
3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire
Specifications
Brand Name :
Henger
Model Number :
3.3*6.5m
Certification :
CCS BV certification ISO17357 ISO9001
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
50pcs week
Delivery Time :
5-8days
Packaging Details :
pallet
Material :
Natural Rubber
Application :
STD,STS
Size :
Customized
Warranty period :
24 months
Design using life :
10 years
Description

3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire

1. Pneumatic rubber fender introduction

Inflatable rubber fender (by ball) is a marine anti-collision product made of compressed air. Compressed air is mainly used as the buffer medium to absorb the impact energy of the ship, making the ship more flexible and soft when docking, so as to achieve the effect of collision and collision avoidance. Yokohama type ball is a kind of sheath type ball. Usually aircraft tires or engineering tires are used to wrap the ball. Both ends are equipped with shoulder straps, which are widely used for ship-to-ship transfer operations and ship berthing operations. Wait. The size is: D0.5m x L1.0m ~ D3.3m x L6.5m. Inflatable fenders (by ball) are produced in strict accordance with ISO17357-2002 and GB/T 21482-2002 international quality standards, and their products are exported to all over the world.

3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire

3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire

2.. Pneumatic rubber fender Parameter

Ship Tonnage(T)

Recommendation SizeD×L(m)

Ship Type

50

0.5*1.0

Fishing ship

100

0.7*1.5~1.0*1.5

Fishing ship

200

1.0*1.5~1.2*2.0

Fishing ship,towing ship

300-500

1.2*2.0~1.5*2.5

Fishing ship,towing ship

1000

1.5*2.5~1.5*3.0

Towing ship,cargo ship

3000

2.0*3.0~2.0*3.5

cargo ship,ocean trawler

10000

2.0*3.5~2.5*4.0

cargo ship

3. Pneumatic rubber fender Parameter

Pneumatic 80 fender size and performance requirements

Nominal size diameter x length

mm

Initial internal pressure

kPa

Guaranteed energy absorption (GEA)

Reaction force at GEA deflection (R)

Hull pressure (Internal pressure) at GEA deflection (P)

Minimum value at deflection 60±5% kJ

Tolerance±10% kN

Reference value

kPa

500 x 1000

80

8

85

174

600 x 1000

80

11

98

166

700 x 1500

80

24

180

177

1000 x 1500

80

45

239

160

1000 x2000

80

63

338

174

1200 x 2000

80

88

390

166

1350 x 2500

80

142

561

170

1500 x 3000

80

214

761

174

1700 x 3000

80

267

840

168

2000 x 3500

80

430

1150

168

2500 x 4000

80

925

1815

180

2500 x 5500

80

1317

2653

195

3300 x 4500

80

1640

2476

171

3300 x 6500

80

2532

3961

191

3300 x 10600

80

4281

6907

208

4500 x 9000

80

6633

7551

192

4500 x 12000

80

9037

10490

202

4. Pneumatic Rubber Fender Features

♦ Advantage:

● Safety and Reliability

● No Deterioration or Variation in Performance● Advantages at Inclined Berthing

● Most Cost Competitive System● Soft Reaction Force for Ship and Jetty Structure

● Lower Mooring Forces under Rough Weather Conditions

3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire

3.3*6.5m Ship Fender For STS Black Pneumatic Fender With Chain And Tire

Tag: inflatable marine fenders,

hydro pneumatic fender,

marine boat fenders
