CY1L Professional Magnetic Pneumatic Cylinder , SMC Rodless Air Cylinder
CY1L Professional Magnetic Pneumatic Cylinder , SMC Rodless Air Cylinder
Specifications
Brand Name :
NBSANMINSE
Model Number :
CY1L
Certification :
ISO9001
Place of Origin :
NINGBO
MOQ :
20
Price :
Negotiation
Supply Ability :
10000 pcs
Delivery Time :
Negotiation
Packaging Details :
plastic bags,boxes, carton, pallet or as customer advice
Bore size ( mm ) :
6 , 10 , 15 , 20 , 25 , 32 , 40
Fluid :
Air
Temperature :
- 10 to 60 ℃ ( No Freezing )
Piston Speed :
50 to 500 mm / s
Cushion :
Rubber bumper / Shock absorber
Lubrication :
Not required ( Non - lube )
Description

CY1L Professional Magnetic Pneumatic Cylinder , SMC Rodless Air Cylinder

Why choose us


1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping.
3: High quality with competitive price.
4: Sample order & small quantity order is acceptable.
5: Customize according to your special request.
6: Provide free products information.
7: Reliable quality assured and active after-sell service
8: One year quality guarantee
9: Technical support via ina@pneuhydr.com

Specifications

Bore size (mm) 6 10 15 20 25 32 40
Fluid Air
Proof pressure 1.05 MPa
Maximum operating pressure 0.7 MPa
Minimum operating pressure 0.18 MPa
Ambient and fluid temperature -10 to 60℃ (No freezing)
Piston speed* 50 to 500 mm/s
Cushion Rubber bumper/Shock absorber
Lubrication Not required (Non-lube)
Stroke length tolerance (mm)

0 to 250 st:+1.0 , 251 to 1000 st: +1.4, 1001 st and up : +1.8
0 0 0
Holding force (N) Type H 19.6 53.9 137 231 363 588 922
Type L - - 81.4 154 221 358 569
Standard equipment Auto switch mounting rail

Standard Stroke

Bore size
(mm)

 Standard stroke (mm) Maximum available stroke (mm)
6 50,100,150,200 300
10 50,100,150,200,250,300 500
15

50,100,150,200,250,300,350
400,450,500

 750
20

100,150,200,250,300,350
400,450,500,600,700,800

 1000
25 1500
32
40

100,150,200,250,300,350
400,450,500,600,700,800
900,1000

 1500

Shock Absorber Specifications

Applicable rodless cylinder

6
CY1L10
15

 CY1L20 CY1L25

CY1L32
40
Shock absorber model RB0805 RB1006 RB1411 RB2015
Maximum energy absorption: (J) 0.98 3.92 14.7 58.8
Stroke absorption: (mm) 5 6 11 15
Collision speed: (m/s) 0.05 to 5
Max. operating frequency : (cyde/min)* 80 70 45 25
Ambient temperature range -10 to 80 ℃
Spring force: (N) Extended 1.96 4.22 6.86 8.34
Retracted 3.83 6.18 15.3 20.50

CY1L Professional Magnetic Pneumatic Cylinder , SMC Rodless Air CylinderCY1L Professional Magnetic Pneumatic Cylinder , SMC Rodless Air Cylinder


Our products are high quality with 12 month guarantee ,and support paypal payment.
