31.5Mpa High Pressure Hydraulic Accumulator Piston Type Accumulator Long Service Life
31.5Mpa High Pressure Hydraulic Accumulator Piston Type Accumulator Long Service Life
Specifications
Brand Name :
NBSANMINSE
Model Number :
HXQ
Place of Origin :
China
MOQ :
20
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
Negotiation
Delivery Time :
Negotiation
Packaging Details :
Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Nominal Volume :
0.25 - 400L
Medium :
Hydraulic oil,emulsion,others
Type :
Actuator
Product Name :
Hydraulic Piston Accumulator
Nominal Pressure :
10 , 20 , 31.5 ~ 99 MPa
Connection Type :
Thread ,Flange
Description

HXQ Hydraulic Piston Accumulator Long Service Life 31.5Mpa High Pressure Accumulator For Hydraulic oil and Emulsion

Hydraulic item pressure range is 0-300bar(30Mpa)

Please don't work more than indicated pressure range.
Attention

The accumulator or air compressor can't be shipped by air recently, here are two methods to ship

1)Shipped by sea,buy accumulators or air Compressor mixed with other products at least 0.5cbm

delivery time is around 30- 35 days

sea freight is 50-100$ per cbm

2)Through your country's agents in China,can pay RMB or USD(paypal)

Any confuse,please contact us on line

CAUTION
only nitrogen is permitted for the accumulator . Oxygen , compressed air , combustibe/exposive gas and other unknow gas shall be strictly prohibited for the explosion risk.
Weight KG
HXQ-L-2.5/20-Y-100
41.5
HXQ-L-39/31.5-Y-180
257.7
HXQ-L-2.5/31.5-Y-100
41.5
HXQ-L-45/31.5-Y-180
279.8
HXQ-L-3/31.5-Y-100
46.4
HXQ-L-50/31.5-Y-180
300
HXQ-L-5/20-Y-100
53.6
HXQ-L-50/20-Y-250
364
HXQ-L-5/31.5-Y-100
53.6
HXQ-L-50/31.5-Y-250
364
HXQ-L-6/31.5-Y-100
53.6
HXQ-L-60/20-Y-250
398
HXQ-L-7.5/20-Y-100
75.7
HXQ-L-60/31.5-Y-250
398
HXQ-L-7.5/31.5-Y-100
75.7
HXQ-L-80/20-Y-250
475
HXQ-L-10/31.5-Y-180
101.8
HXQ-L-80/31.5-Y-250
475
HXQ-L-16/31.5-Y-180
160.4
HXQ-L-100/20-Y-250
543
HXQ-L-20/31.5-Y-180
175.8
HXQ-L-100/31.5-Y-250
543
HXQ-L-25/31.5-Y-180
195
HXQ-L-120/20-Y-250
612
HXQ-L-32/31.5-Y-180
230.9
HXQ-L-120/31.5-Y-250
612
HXQ Series piston type accumulator , designed by our factory , with complete product specifications . We can design according customer request . Piston accumulator advantage with good sealing , no leakage , high temperature resistance , long service life .
Ordering Code
Product Name : Piston Accumulator
Connection Type : L – Thread Connection , F – Flange Connection
Nominal Volume : 0.25 ~ 400L
Nominal Pressure : 10 , 20 , 31.5 ~ 99 MPa
Medium : Y – Hydraulic Liquid , R – Emulsion , Q - Others
