Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Polcd 2.4 Inch MCU Interface TFT Display Driver IC ST7789V2 240x320 Resolution 2.4 inch TFT LCD Modules
Specifications
Brand Name :
Polcd
Model Number :
P024B040-IPS
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T, L/C, Credit card, PayPal, D/A, D/P, Western Union, MoneyGram
Supply Ability :
25,000 PCS per day
Delivery Time :
1-7 working days
Packaging Details :
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Resolution :
240x320
Interface :
MCU 8/16BIT
Driver IC :
ST7789V
Brightness (cd/m²) :
450 nit
Viewing Angle :
IPS all viewing angle
Display area :
36.72(H)x48.96(V) mm
Description

Description of 2.4 inch TFT LCD :

2.4 inch TFT LCDs are commonly used in a variety of electronic devices, including handheld gaming devices, automotive displays, industrial controllers, medical devices, and smart home devices. They typically have low power consumption, wide viewing angles, and can be customized to meet specific application requirements, including touch screen support and different backlight options.

Parameter:

Item Specification
Model P024B040-IPS
Screen Size 2.4 inch
Number of Pixel 240RGB(H)x320(V)
Display area 36.72(H)x48.96(V)mm
Pixel pitch 0.153(H)x0.153(V)mm
Pins 40 pins
Outline Dimension 42.72x60.26x2.30mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally Black
Viewing Direction(eye) ALL
Gray inversion direction --
Display Color 262K
Luminance(cd/m2) 450 nit
Contrast Ratio 1200:1
Surface treatment --
Interface MCU 8/16BIT
Back-light LED Side-light type
Drive IC ST7789V
Operation Temperature -20~70℃
Storage Temperature -30~80℃
