Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Polcd 2.8 inch 240*320 Spi Mcu interface Tft Lcd Color Display Module Transflective LCD screen
Specifications
Brand Name :
Polcd
Model Number :
P028BFT01-40
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T, L/C, Credit card, PayPal, D/A, D/P, Western Union, MoneyGram
Supply Ability :
25,000 PCS per day
Delivery Time :
1-7 working days
Packaging Details :
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Size (inch) :
2.8
Resolution :
240*320
Brightness (cd/m²) :
300 nit
Display area :
43.20(H)x57.60(V)mm
Interface :
MCU 8/16bit SPI 3wire/4wire
Driver Ic :
ST7789T3
Description

Parameter:

Model P028BFT01-40
Screen Size 2.8 inch
Number of Pixel 240RGB(H)x320(V)
Display area 43.20(H)x57.60(V)mm
Pixel pitch 0.06(H)x0.18(V)mm
Pin 20 pin
Outline Dimension 50.00x69.20x2.30mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally White
Viewing Direction(eye) Transflective
Display Color 262K
Luminance(cd/m2) 300 nit
Contrast Ratio 500:1
Interface MCU 8/16bit SPI 3wire/4wire
Back-light 4*LED Parallel type
Drive IC ST7789T3
Operation Temperature -20~70℃
Storage Temperature -30~80℃
