Polcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD Display
Polcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD Display
Polcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD Display
Polcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD Display
Polcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD Display
Polcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD Display
Polcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD Display
Polcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD Display
Specifications
Brand Name :
Polcd
Model Number :
P030H005-IPS-V2
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T, L/C, Credit card, PayPal
Supply Ability :
500,000 piece per week
Delivery Time :
1~7 working days
Packaging Details :
20 cm * 30 cm * 40 cm
Screen Size :
3 inch
Resolution :
268x800
Brightness (cd/m²) :
700 nit
Interface :
RGB565
Driver Ic :
ST7701S
Description

Parameter:

Model P030H005-IPS-V2
Screen Size 3 inch
Number of Pixel 268RGB(H)x800(V)
Display area 24.12(H)x72(V)mm
Pixel pitch 0.09(H)x0.09(V)mm
Pins 40 pins
Outline Dimension 26.96x80.08x1.75mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally Black
Viewing Direction(eye) ALL
Display Color 262K
Luminance(cd/m2) 700 nit
Contrast Ratio 1200:1
Interface RGB565
Back-light LED Side-light type
Drive IC ST7701S
Operation Temperature -20~70℃
Storage Temperature -30~80℃

Polcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD DisplayPolcd IPS 268x800 ST7701S High Brightness 700nits 3.0 inch TFT LCD Screen LCD Display
