Motorcycle camera
Features
4 glass wide-angle professional lens
Using the latest wide dynamic technology, the imaging effect is more ideal under strong light / weak light environment
High definition RGB display
Automatic recording of motorcycle start, automatic shutdown after 5S delay
No gap and no missing seconds continuous recording function, no data will be missed
Built-in collision sensor, real-time three-axis stereo detection of vehicle collision status, abnormal collision will start sudden collision recording (this file will not be overwritten)
Powerful file protection function, if there is a sudden power failure, machine damage, etc., the video file will still be completely saved
Automatic loop overlay video
Temporary manual closing and opening of video
Temporary manual emergency lock of important videos
Manually turn recording on and off
Can set the time to turn off the screen automatically. Turning off the screen does not affect the normal recording work, etc.
Video files can be played back at any time
Deformation-free high-definition shooting device with clear images and no smear
With professional high and low temperature resistant suction cup bracket, easy to install and use
Over-voltage and over-current protection
Built-in polymer lithium battery prevents high temperature .
Specifications | |
Master Control | 5401 / 5203B |
Front lens | AHD2053/H65/H62/V06 |
Rear lens | AHD2053/H65/H62/V06 |
Display screen | 3.0-inch IPS color 16: 9 HD screen |
Effective Pixels | 1920 * 1080 front camera |
Video format | MOV format |
Video compression | MJPG |
Frame rate | 1080P/30f/s |
Photo format | JPEG |
Photo size | maximum 12M 4032 * 3024 resolution |
Collision sensor | Three-axis stereo collision detection |
Recording mode | VGA format, loop recording |
Intermittent recording | 0ms |
Memory | Support TF memory card 4GB ~ 32GB |
AP encrypted player | Native system format automatically generates AP player |
Start time | 2S |
Working voltage | DC 5V |
Working current | 650mA |
Quiescent current | <100uA |
Storage temperature (℃) | (-20℃-70℃) |
Operating temperature(℃) | (0℃-60℃) |
Operating humidity(RH) | 15%-60%RH |
Battery type | High temperature polymer lithium battery 180mAH |
Housing Material | Zinc Alloy Housing |
Package size | 190*110*72MM |
product weight | 0.4KG
|
