High Power Polycrystalline Solar Panel Guaranteed Positive Output Tolerance 0-3%
High Power Polycrystalline Solar Panel Guaranteed Positive Output Tolerance 0-3%
Specifications
Brand Name :
OLLIN PV
Model Number :
OL-36P-160
Certification :
CE ROSH ISO
Place of Origin :
zhejiang Pr, China
MOQ :
one unit
Price :
Negotiable
Supply Ability :
1500UNITS PER WEEK
Delivery Time :
20DAYS
Packaging Details :
2pcs/CTN, 1700PCS/40hq container
Name :
Polycrystalline Solar Panel
cell array :
4*9
cell color :
blue
Advantage :
High Power
front sheet :
high transmissions low iron tempered glass
Packing :
2pcs/CTN, 1700PCS/40hq container
Main market :
Asia Africa Southeast Asia
Junction box :
JB with 0.9m wire and connector
Description

High Power Polycrystalline Solar Panel Guaranteed Positive Output Tolerance 0-3%

Polycrystalline Solar Panel Key Features

160Watt solar panel has several uses including marine , dry camp , and other off-grid applications. Whether you are going camping in the mountains or taking a trip to the beach , this panel can be a great start to your off-grid system .

High modules conversion efficiency solar panel Withstand high wind (2400Pa) and snow loads (5400Pa) and Guaranteed Positive Output Tolerance (0-3%)



Polycrystalline Solar Panel Electrical Characteristics

OLLIN-130P-160P
Polycrystalline Solar Module
Mechanical Data
Cell type Poly156mm*156mm
No.of cells 36 in series(4*9)
Dimensions 1480*680*40mm
Weight 10kg
Electrical Data
Under STC ( Standard Test Conditions:1000W/m2 25℃, AM1.5)
Power 130WP 150WP

160WP
Open circuit voltage(Voc) 21.5V 21.5v 21.6V
Max. power voltage(Vmp) 17.46V 17.48V 17.5V
Short circuit current(Isc) 7.8A 8.99A 9.59A
Max. power current(Imp) 7.2A 8.3A 8.89A
A grade power Tolerance ± 3%
Max.system voltage 1000V
Operating temp. —40℃~80℃
Temperature coefficients of Pmax -0.47% /℃
Temperature coefficients of Voc -0.38% /℃
Temperature coefficients of Isc +0.1% /℃

Products information

  1. With advanced materials and equipment, our modules are designed and manufactured
  2. in consistency with the IEC 61215:1993 standards which can guarantee the excellent electrical
  3. performance and the product life of 25 years.
  4. A film of PECVD is coated on the upper surface as anti-reflection measure, featuring deep blue color.
  5. The modules are embedded with a sheet of imported strong transparent glass, two sheets
  6. of long endurance EVA, a high efficiency monocrystalline cells sheet and a sheet of antihumidity
  7. TPT for different weather conditions.
  8. High quality anodized aluminum frame is suitable for strong wind resistance and mountain terrain.
  9. A multifunction box ensure safe connection.
  10. The exterior design and electrical performance of the module can meet the requirements of superior quality.

Solar Photovoltaic is the technology by which solar energy is converted into

electrical energy and its major applications in industrial and commercial sectors:

  1. Solar Homes Systems upto 2000 W,
  2. Solar Lighting,
  3. Solar Power Plants from 10 KW to 20 MW,
  4. Solar Parks upto 20 MW,
  5. Solar UPS,
  6. Solar Roof Based On Grid Power Generation,
  7. Solar Traffic Signals Lights,
  8. Power for Remote Terminal Units,
  9. Power for Telecommunication Towers and BSC and MSC,
  10. Building Integrated Photovoltaic System,
High Power Polycrystalline Solar Panel Guaranteed Positive Output Tolerance 0-3%
