Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters
Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters
Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters
Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters
Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters
Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters
Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters
Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters
Specifications
Brand Name :
Share Filters
Model Number :
Mesh Filter Tube
Certification :
SGS
Place of Origin :
China
MOQ :
100pcs
Price :
USD0.10-USD0.90/pc
Payment Terms :
T/T, L/C, Western Union, Payple
Supply Ability :
20000pcs/day
Delivery Time :
5-10 days
Packaging Details :
Caron, Polybag
Products Name :
Mesh Filter Tube
Material :
Nylon filter mesh, Polyester filter mesh, stainless steel mesh
Seam Type :
Heat welding, Sonic welding
Seam No :
One seam, Two seams
Supply Form :
Rolls, Cut to length
Key word :
Nylon filter mesh tube
Application :
automotive filters, aerospace filters and healthcare filters
Description

Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters

Share Filters not only manufactures and supplies the filter mesh in rolls, but also has the capability to convert the filter mesh to be various of ribbons, shapes, tubes. After slitting, the mesh ribbons can be ultrasonic cutting , welding or stitched to tubes. Some filter products will need to take more complex forms and will require a specialist in the industry to achieve the best results, the welded tube make the insert injection molding easier. Share filter mesh tubes are used in a variety of applications or products, such as: automotive filters, appliance filters and healthcare filters.

Filter mesh having thread diameters < 250 µm and mesh openings < 500 µm can be ultrasonically welded.

Filter mesh with thread diameters < 250 µm and mesh openings < 500 µm can be heat slit.

Filter Mesh Options

Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters Product Name Woven filter mesh tube
Color White, Yellow and other colour
Material Nylon mesh, polyester mesh, PP mesh
Certificate SGS
Weave type Plain Woven
Mesh Opening 16-2000μm
Fabric Width

100cm, 127cm, 150cm, 160cm, 175cm, 183cm, 365cm or customized
Roll length 30, 50, 70 and other custom length
Mesh Count 13mesh~510 Mesh/inch)
Samples supply 5-10pcs free sample

Filter Mesh Tubes Types

Tube with only one functional seam

Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters


 Hot and ultrasonic cutting technologies, the tubes are equipped with one or two functional seams, which provide the necessary seam strength, usually used for injection molding
Tube with two functional seams

Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters


 Dual-layer slit tubes have two edges on the side of the tube, heat slitting and ultrasonic slitting
Tube with one overlapping ultrasonic welding edge

Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters


 Ultrasonic welded tubes have one overlapping weld and like in the ultrasonic slitter, filter mesh having thread diameters < 250 µm and mesh openings < 500 µm can be ultrasonically welded
Continous Tube Rolls

Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters


 Tube rolls are packed into PE bags that are closed by welding
Cut to length
Nylon Polyester Filter Mesh Tube By Ultrasonic Thermal Welding For Automotive Filters Cut to custom length


Nylon Filter Mesh Datasheet

Ref. No. Mesh Count Thread Diam. Mesh Opening Opening Area
mesh/cm mesh/inch µm µm %
JPP5 5 12 500 1500 56
JPP6 6 16 400 1267 58
JPP7 7 18 350 1079 57
JPP8 8 20 350 900 52
JPP9 9 24 250 860 60
JPP10 10 25 300 700 49
JPP12 12 30 250 583 49
JPP12 12 30 300 533 41
JPP14 14 35 300 414 34
JPP16 16 40 200 425 46
JPP16 16 40 250 375 36
JPP20 20 50 150 350 49
JPP20 20 50 200 300 36
JPP24 24 60 150 267 41
JPP28 28 70 120 237 44
JPP30 30 76 120 213 41
JPP32 32 80 100 213 46
JPP36 36 90 100 178 41
JPP40 40 100 100 150 36
JPP43 43 110 80 152 43
JPP48 48 120 80 130 38
JPP56 56 140 60 120 44
JPP59 59 150 60 110 42
JPP64 64 160 60 100 37
JPP72 72 180 50 90 41
JPP80 80 200 50 75 36
JPP100 100 250 40 60 36
JPP120 120 305 40 43 25
JPP130 130 330 40 37 23
JPP140 140 355 30 38 33.7
JPP150 150 381 30 34 30.25
JPP165 165 420 30 28 20.7
JPP180 180 460 30 25 19.5
JPP200 200 510 30 16 10.2
