PA-22GG-950 Nylon Woven Filter Fabric Mesh Width 130CM For GG Flour Milling
PA-22GG-950 Nylon Woven Filter Fabric Mesh Width 130CM For GG Flour Milling
PA-22GG-950 Nylon Woven Filter Fabric Mesh Width 130CM For GG Flour Milling
PA-22GG-950 Nylon Woven Filter Fabric Mesh Width 130CM For GG Flour Milling
Specifications
Brand Name :
SHARE
Place of Origin :
CHINA
MOQ :
100meters
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Delivery Time :
5-7days
Packaging Details :
Carton
Model Number :
22GG
Certification :
SGS
Material :
Polyamide
Mesh Count :
12GG-74GG
Weave :
Plain Woven 1:1
Width :
130cm, 145cm
Yarn Type :
Mono-filament
Color :
White
Mesh Opening :
950um
Application :
GG Flour Milling
Filtration :
Coarse Filtration
name :
Nylon Woven Filter Fabric
Description

PA-22GG-950 Polyamide Flour Sifting and Milling Mesh

SHARE POLYAMIDE FLOUR MILLING MESH-PA-22GG-950UM

PA-22GG-950um

Mesh Count: 20tpi (threads per inch)
Thread Diameter: 300um
Mesh Opening: 950um
Width: 130cm

1. General Introduction:

  • Material: Food grade nylon PA6 (i.e. nylon, polyamide) or polyester (i.e. polyester, PET)

  • Specification: 12GG-74GG, 2000-212 um aperture

  • Weaving Type: Plain Weave

  • Width: 105 cm, 115 cm, 136 cm, other widths can be available upon customised order

2. Characteristics/advantages of Flour Mesh offered by SHARE

  • High throughput

  • High yield

  • Long service life

  • High reliability

  • Wide product range​

3. Main applications:

  • Food processing screening filter,

  • Plansifter in flour milling,

  • Single and double bin flat screen,

  • Aluminium alloy screen,

  • Grinder screen,

  • Powder cleaner screen,

  • Vibration screen,

  • Sieve bone,

  • Press filter cloth,

  • Starch filter cloth, etc

4. Datasheet:

Fabric
No.

Mest Count

Thread Diameter

(um)

Mesh Opening

(um)

Open Area (%)

Weight(gsm)

Width

n/cm

n/inch

inch

40

54

57

cm

136

PA-10GG

3.94

10

550

1990

61

237

●

PA-12GG

4.33

11

400

1820

67

153

●

PA-14GG

5.11

13

400

1600

64

170

●

PA-16GG

5.90

15

350

1317

62

156

●

PA-18GG

6.69

17

350

1180

59

170

●

PA-20GG

7.48

19

300

1023

60

144

●

PA-22GG

7.87

20

300

950

58

153

●

PA-24GG

8.66

22

300

850

56

163

●

PA-26GG

9.05

23

300

800

54

172

●

PA-28GG

10.62

27

250

705

54

140

●

PA-30GG

11.02

28

250

659

53

146

●

PA-32GG

11.41

29

250

610

51

153

●

PA-34GG

11.81

30

250

570

49

159

●

PA-36GG

12.59

32

250

530

47

166

●

PA-38GG

14.17

36

200

500

52

119

●

PA-40GG

14.56

37

200

486

50

123

●

PA-42GG

14.96

38

200

466

49

128

●

PA-44GG

16.14

41

200

425

46

136

●

PA-46GG

16.92

43

200

388

44

145

●

PA-48GG

17.71

45

200

364

42

148

●

PA-50GG

18.11

46

200

355

41

153

●

PA-52GG

20.47

52

150

338

48

98

●

PA-54GG

21.65

55

150

315

46

103

●

PA-58GG

22.04

56

150

300

44

105

●

PA-60GG

22.83

58

150

285

43

110

●

PA-62GG

23.62

60

150

273

42

112

●

PA-64GG

24.01

61

150

266

41

115

●

PA-66GG

28.34

72

100

252

51

61

●

PA-68GG

29.13

74

100

243

50

63

●

PA-70GG

29.52

75

100

238

48

64

●

PA-72GG

30.31

77

100

229

47

66

●

PA-74GG

31.88

81

100

213

46

69

●

5. Packing

PA-22GG-950 Nylon Woven Filter Fabric Mesh Width 130CM For GG Flour Milling

PA-22GG-950 Nylon Woven Filter Fabric Mesh Width 130CM For GG Flour Milling
