Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
Specifications
Brand Name :
Dahua Sling
Model Number :
web sling
Certification :
BS EN 1492-1:2000
Place of Origin :
China
MOQ :
1000 pcs
Price :
USD 30,000 / 20'GP
Logo :
We do it oursleves
Eye protector :
White Black or same as webbing
Material :
100 % polyester
Layer: :
1 layer
packing :
Blank or printed one way sling
Sling type :
endless flat webbing sling
W.L.L :
250 kg endless sling 750 kg one way sling 1500 kg diposable sling
COLOR :
Yellow
standard :
BS EN 1492-1:2000
Description

Single Use, One Way, Polyester Webbing Seat Belt Round Sling / endless slings. 7:1 Ratio FOS - Range from 250kg to 1000k

Standard slings are available in 1000mm, 1200mm, 1600mm and 1800mm circumferences which is divided by 2 to calculate the Effective Working Length (EWL), due to them being endless belts, however other lengths are available as special/custom/bespoke units.

*Safety Factor is calculated as Working Load Limit (WLL) multiplied by a factor of 7 to equal minimum breaking force

Features

  • Single Use - One Way
  • Low cost, simple design
  • Easy to use
  • Stronger and more compact than rope or wire rope alternative solutions.
  • Can be attached or built in to a structure or load, but must only be used to perform a single complete lift.
  • Saves time and cost on-site slinging and reslinging loads.
  • Fully manufactured, labelled and tested in accordance with BS EN 1492-1:2000 or upon request, manufactured to your commercial specifications with supporting technical file.
  • Available as standard in 25mm, 35mm and 50mm widths in endless format or as bespoke units with loops each end.

Specimin Test Results

  • Product Type: One Way Sling
  • Webbing type: Polyester Seat Belt
  • Webbing Width: 48mm
  • Test Name: Tensile Test
  • Test Type: Tensile
  • Test Date: 08/03/2007 16:43
  • Test Speed: 100.00mm/min
  • Pretension: 0.050 N
  • Sample Length: 1000.000mm
  • Force at Peak (kN) = 43.910
  • Elongation at Break (mm) = 80.602
  • Time to Failure (Secs) = 48.280

Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings

Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings

Endless sling (Type 5)
Plies of Web Model Wed Width (in.) Rated Capacity (lbs.) base Length(ft)
Vertical
Chocker
Vertical Basket
One Ply SEN1-1 1 2400 1920 4800 3
SEN1-2 2 4800 3840 9600 3
SEN1-3 3 6600 5280 13200 3
SEN1-4 4 8800 7040 17600 3
SEN1-5 5 11000 8800 22000 3
SEN1-6 6 13200 10560 26400 3
Two Ply SEN2-1 1 4800 3840 9600 3
SEN2-2 2 9600 7680 19200 3
SEN2-3 3 12500 10000 25000 3
SEN2-4 4 15500 12400 31000 3
SEN2-5 5 19400 15520 38800 3
SEN2-6 6 23000 18400 46000 3


Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings

Large Capacity Long Green Lifting Straps , Certified Disposable Lifting Slings
