Yellow Synthetic Fibre Endless Round Slings Flat Straps 3000kg En1492-2
Yellow Synthetic Fibre Endless Round Slings Flat Straps 3000kg En1492-2
Specifications
Brand Name :
Dahua Sling
Model Number :
web sling
Certification :
BS EN 1492-1:2000
Place of Origin :
China
MOQ :
1000 pcs
Price :
USD 30,000 / 20'GP
Logo :
We do it oursleves
Eye protector :
White Black or same as webbing
Material :
100 % polyester
HS Code of round sling :
HS Code: 56090000
packing :
Blank or printed
Sling type :
endless flat webbing sling
W.L.L :
3000KG
COLOR :
yellow
standard :
BS EN 1492-1:2000
Transport Package: :
Carton
Type: :
Synthetic Fibre Sling
Description

En1492-2 Polyester Endless Round Sling 3000kg yellow made to order

Product description:

Product Name round sling; endless sling,polyester webbing sling,lifting sling
Material Polyester
Size 6-180t
Color standard(green/blue/yellow/red,etc)
Packing carton or as required
Safety Factor 5:1 and 6: 1 and 7: 1
Certification GS, SGS, CE;ROHS; ISO9001


TS-R01 Round sling ( Single Ply Sleeve )

Item No. WLL
(kg)		 Dia
(mm)		 L(m) S.F 7:1
Min Max
TS-R01-01 1000 6 0.5 100 0.30
TS -R01-02 2000 7 0.5 100 0.44
TS -R01-03 3000 8 0.5 100 0.65
TS -R01-04 4000 9 1.0 100 0.83
TS -R01-05 5000 11 1.0 100 1.01
TS -R01-06 6000 12 1.0 100 1.19
TS -R01-08 8000 13 1.0 100 1.50
TS -R01-10 10000 15 2.0 100 1.95
TS -R01-12 12000 16 2.0 100 2.46
TS -R01-15 15000 18 2.0 100 2.97
TS -R01-20 20000 20 2.5 100 4.66
TS -R01-25 25000 24 2.5 100 5.84
TS -R01-30 30000 32 2.5 100 9.23
TS -R01-40 40000 40 2.5 100 12.1
TS -R01-50 50000 45 2.5 100 14.1
TS -R01-60 60000 65 4.0 100 17.3
TS -R01-80 80000 70 4.0 100 22.2
TS -R01-100 100000 80 4.0 100 26.0
TS -R01-120 120000 5.0 100
TS -R01-150 150000 5.0 100
TS -R01-200 200000 120 5.0 100 64.0
TS -R01-250 250000 5.0 100
TS -R01-300 300000 160 5.0 100 79.0
TS -R01-350 350000 5.0 100
TS -R01-400 400000 200 5.0 100 98.4
TS -R01-450 450000 5.0 100
TS -R01-500 500000 220 8.0 100 121.2

TS-R02 Round sling (Double Ply Sleeve )
Item No. WLL
(kg)		 Dia
(mm)		 L(m) S.F 7:1
g/m
Min Max
TS-R02-01 1000 15 0.5 100 0.33
TS -R02-02 2000 16 0.5 100 0.47
TS -R02-03 3000 18 0.5 100 0.68
TS -R02-04 4000 20 1.0 100 0.85
TS -R02-05 5000 25 1.0 100 1.06
TS -R02-06 6000 27 1.0 100 1.28
TS -R02-08 8000 28 1.0 100 1.59
TS -R02-10 10000 29 2.0 100 2.10

TS-R03 Eye-Eye Round sling
Item No. WLL
(kg)		 Dia
(mm)		 L
Min Max
TS -R03-01 1000 11 1.0 80
TS -R03-02 2000 12 1.5 80
TS -R03-03 3000 14 1.5 80
TS -R03-04 4000 15 1.5 80
TS -R03-05 5000 23 1.5 80
TS -R03-06 6000 25 2.0 80
TS -R03-08 8000 26 3.0 80
TS -R03-10 10000 27 3.0 80
TS -R03-15 15000 29 3.0 80
TS -R03-20 20000 31 3.0 80
TS -R03-25 25000 34 3.0 80
TS -R03-30 30000 36 4.0 80
TS -R03-40 40000 40 4.0 80
TS -R03-50 50000 46 5.0 80
TS -R03-80 80000 5.0 80
TS -R03-100 100000 5.0 80
TS -R03-150 150000 5.0 80
TS -R03-200 200000 5.0 80

TS-R04 High-Strength Round sling
Item No. WLL
(kg)		 Dia
(mm)		 L(M) S.F 7:1
g/m
Min Max
TS -R04-05 5000 23 1.5 80
TS -R04-06 6000 25 2.0 80
TS -R04-08 8000 26 3.0 80
TS -R04-10 10000 27 3.0 80
TS -R04-15 15000 29 3.0 80
TS -R04-20 20000 31 3.0 80
TS -R04-25 25000 34 3.0 80
TS -R04-30 30000 36 4.0 80
TS -R04-40 40000 40 4.0 80
TS -R04-50 50000 46 4.0 80
TS -R04-60 60000 4.0 80
TS -R04-80 80000 4.0 80
TS -R04-100 100000 5.0 80
TS -R04-120 120000 5.0 80
TS -R04-150 150000 5.0 80
TS -R04-200 200000 5.0 80
TS -R04-250 250000 5.0 80
TS -R04-300 300000 5.0 80

TS-R05 U.S Round Sling SF 5:1
Item No. WLL
(LBS)		 Dia
(IN)		 Length:(FT)
Min Max
TS-R05-01 2600 6 0.5 300
TS -R05-02 5300 7 0.5 300
TS -R05-03 8400 8 0.5 300
TS -R05-04 10600 9 0.5 300
TS -R05-05 13200 11 0.5 300
TS -R05-06 16800 12 1.0 300
TS -R05-07 21200 13 1.0 300
TS -R05-08 25000 15 2.0 300
TS -R05-09 31000 16 2.0 300
TS -R05-10 40000 18 2.0 300
TS -R05-11 53000 20 2.5 300
TS -R05-12 66000 24 2.5 300
TS -R05-13 90000 32 2.5 300
TS -R05-14 100000 40 2.5 300

TS-R06 Marine Rope
Item No. Dia(mm) Polyester
Kg/m M.B.L(ton) Kg/m M.B.L(ton)
TS-R06-01 40 1.22 26 0.9 116
TS -R06-02 44 1.5 31 1.1 132
TS -R06-03 48 1.8 36 1.3 156
TS -R06-04 52 2.1 42 1.56 175
TS -R06-05 56 2.4 48 1.88 212
TS -R06-06 60 2.8 53 2.05 230
TS -R06-07 64 3.15 60 2.35 264
TS -R06-08 72 4.0 75 3.0 337
TS -R06-09 80 4.9 93 3.7 416
TS -R06-10 88 5.9 112 4.5 503
TS -R06-11 96 7 132 5.3 590


In-service Inspection, Maintenance and Replacement

Inspect slings each day before use, looking for:

  • Missing or unreadable ID tag
  • Melted, charred or weld-splattered areas
  • Acid or alkali burns
  • Holes, tears, cuts, snags or embedded particles
  • Broken or worn stitching
  • Excessive abrasive wear or elongation
  • Knots or brittle areas
  • Broken, corroded, pitted distorted fittings

Do not use worn or damaged slings or attachments. Discard or repair them. Use damaged slings only after they are repaired, reconditioned, and proof tested by the sling manufacturer or a qualified person. Keep certificates of proof test.

Maintenance requirements are minimal. Belt slings may be cleaned with clear water. Remember weak chemical
solutions will become increasingly stronger by evaporation. Regularly inspect belt slings and, in the event of the
following defects, refer the sling to a Competent Person for thorough examination: illegible markings; damaged,
chaffed or cut webbing; damaged or loose stitching; heat damage; burns; chemical damage; solar degradation;
damaged or deformed end fittings.
