DN32-DN355 SDR11 SDR17.6 PE Spigot End Cap Polyethylene Pipe Fittings
DN32-DN355 SDR11 SDR17.6 PE Spigot End Cap Polyethylene Pipe Fittings
Specifications
Brand Name :
LUTONG
Model Number :
DN63-DN355
Certification :
BSI
Place of Origin :
CHINA
MOQ :
NEGOTIATION
Price :
NEGOTIATION
Packaging Details :
CARTON
Material :
PE100
Color :
Black
Application :
Gas pipe, water pipe
Welding mode :
Butt fusion
Size :
DN32 - DN355
SDR value :
SDR11, SDR17, SDR17.6
Delivery Time :
NEGOTIATION
Payment Terms :
NEGOTIATION
Supply Ability :
10000 PER MONTH
Description
PE SPIGOT END CAP DN32 - DN355 POLYETHYLENE PIPE FITTINGS SDR11, SDR17, SDR17.6

PE End Cap standard EN1555.3/EN12201.3/ ISO8085/ ISO4427.3;

PE100 SDR11 End Cap applied for gas pipeline pressure reach 0.7Mpa, and water-supply pipeline pressure reach 1,6Mpa;

PE80 SDR11 End Cap applied for gas pipeline pressure reach 0.5Mpa. and water-supply pipeline pressure reach 1.25Mpa;

PE 100 SDR17.6 and SDR17 End Cap applied for gas pipeline pressure reach 0.4Mpa, and water-supply pipeline pressure reach 1 .OMpa;

PE80 SDR 17.6 and SDR17 End Cap applied for gas pipeline pressure reach 0.3Mpa, and water-supply pipeline pressure reach 0.8Mpa;

The length of the welding pipe section can be lengthened according to the requirement.

DN32-DN355 SDR11 SDR17.6 PE Spigot End Cap Polyethylene Pipe Fittings

d mm e(SDR11) mm e(SDR17) mm e(SDR17.6) mm L1 mm L mm
32 3.0 - - 44 60
40 3.7 - - 49 65
50 4.6 - - 55 75
63 5.8 - - 67 90
75 6.8 4.5 4.3 70 105
90 8.2 5.4 5.2 79 124
110 10.0 6.6 6.3 82 137
125 11.4 7.4 7.1 87 149
140 12.7 8.3 8.0 92 162
160 14.6 9.5 9.1 98 178
180 16.4 10.7 10.3 105 195
200 18.2 11.9 11.4 112 212
225 20.5 13.4 12.8 120 232
250 22.7 14.8 14.2 130 255
315 28.6 18.7 17.9 150 307
355 32.2 21.1 20.2 165 342
